6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
Specifications
Operating Weight :
25 ton
Place of Origin :
Shandong, China
Brand Name :
HJH
Moving Type :
Crawler Excavator
Bucket capacity :
1.2-1.4m3
Maximum Digging Height :
10000MM
Maximum Digging Depth :
6620MM
Machine Weight :
24000 kg
Rated Speed :
5.5/3.3km/h
Warranty :
1 Year
Hydraulic Cylinder Brand :
Linde
Hydraulic Pump Brand :
Linde
Hydraulic Valve Brand :
Linde
Engine Brand :
Cummins
UNIQUE SELLING POINT :
High operating efficiency
Power :
124KW
Machinery Test Report :
Provided
Video outgoing-inspection :
Not Available
Warranty of core components :
1 Year
Core Components :
Other, Engine, Pump
Max. dumping height :
7110MM
Max. vertical wall digging depth :
5980MM
Max. digging reach :
9875MM
Min. swing radius :
3040MM
Max. Height at Min. swing radius :
8060MM
Showroom Location :
None
Condition :
New
Marketing Type :
Ordinary Product
Applicable Industries :
Other
Price :
$65,000.00/pieces 1-4 pieces
MOQ :
1 set
Description
Company Profile
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works

About Company
As a manufacturer of accessories for large excavators and bulldozers, we have a comprehensive brand and a wide range of models,
which can provide you with the most favorable price.I look forward to answering your questions about new or used cars.
Click "Query" to get in touch with us!
Product Display
6620MM Maximum Digging Depth 20 Ton Long Carriage Excavator SE210-9 for Earth-Moving Works
Basic parameters
工作重量Working weight
24000KG
发动机额定功率power
124KW/2050rpm
铲斗容量Bucket Capacity
1.2-1.4m3
液压系统Hydraulic System
林德Linde
行走马达Walking motor
日本纳博NABTESCO
发动机型号Engine Model
康明斯Cummins QSB7.0
Dimensions
总长（运输时）mm Overall length
9425
总宽度mm Overall width
2980
总高度（动臂顶部）mm Transport height
2970
上部宽度mm Overall width of upperstructure
2860
总高度（驾驶室顶部）mm Overall height of cab
3040
标准履带板宽度mm Shoe width
600
轨距mm Track gauge
2380
最小离地间隙mm Min. ground clearance
440
尾部回转半径mm Tail swing radius
2710
履带接地长度mm Track ground length
3480
履带长度mm Track length
4260
Performance specifications
整机重量（kg）Machine Weight
24000
斗容m³Bucket capacity
1.1-1.3m³
额定功率KW/rpm Rated Power
124/2050
行走速度（高/低km/h）Travel speed(H/L)
5.5/3.3
回转速度rpm Swing speed
11
爬坡能力（35°）Gradeability
70%
接地比压kpa Ground pressure
46.5
铲斗挖掘力KN Bucket digging force
150
斗杆挖掘力KN Arm digging force
109
Why Choose Us
Service attitude is good
Product quality is guaranteed
Team has been established for a long time and we have rich work experience
Wide global transportation range
Many positive reviews from customers
FAQ
How to solve quality or usage issues that arise after receiving the product?
We will provide online assistance, one-on-one guidance on how to use our products. If there are problems during the warranty period, we will also provide certain compensation or returns.
