Specifications
Brand Name :
HiYi
Model Number :
R310P
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD 1000-4000/pcs
Payment Terms :
L/C,D/A,D/P,D/P,T/T,Western Union,MoneyGram
Supply Ability :
10000 set/month
Delivery Time :
3-7 days
Packaging Details :
alloy case
Name :
HiYi 0.5 5.0μm Customization RS485 LCD Display Independent Pump 1 CFM Cleanroom Remote Particle Counter
Temperature :
0~50℃
Alarm :
Visual/ Audible
Color :
Blue
Explosion-proof :
Laser diode
Protection grade :
IP 65
Size :
120 * 65 * 132 mm
Weight :
6 kg
Description

R310P Built-in Pump Online Particle Counter 28.3L/min


OVERVIEW


The R310P particle sensor can be installed at one or more monitoring points according to the actual site conditions, and the measured data will be displayed directly on the display of each monitoring point. R series dust particle sensors can monitor particles of 0.3μm, 0.5um and 5.0um, and comply with GMP, FDA and ISO21501-4 requirements. Meanwhile, the R series contains several models, so customers can choose the one that suits their needs.


R310P Built-in Pump Online Particle Counter 28.3L/min


FEATURES & BENEFITS


1. Reasonable structure design, compact size, easy installation.


2. Particle size channel: 0.3,0.5,0.7,1.0,3.0,5.0,10.0,25.0 (μm)

3. Sampling flow rate: 1CFM (28.3LPM)

4. Three kinds of status indicator guide:

Power indicator;

Communication indicator;

Measurement status indicator.

5. RS485 (modbus), 4-20mA, WIFI, LORA, TCPIP and other signal output methods can be selected.

6. Using foreign original laser diode and vacuum pump, long service life.

7. 2.4 inch OLED display, readings are intuitive and clear.

8. 316 stainless steel case can be ordered.


SPECIFICATION


Counting efficiency

50%±20％ @ minimum channel size, 100% ±10％for particles >1.5 X - 2X channel particle size

Zero count degree

<1 count/5 minutes (ISO 21501-4 and JIS)

Monitoring range

Class 100 - 300,000

Housing material

304 stainless steel

Standards

JIS B9921；ISO21501-4

Operating environment

10-40℃,20%-95%


​


APPLICATION

Particle Counters are feature-rich instruments that are ideal for spot-checking inside of your critical environments or Indoor Air Quality applications. With its compact size and weight along with its sleek handle, you can utilize this unit with ease.
These units provide immediate results that allow you to proactively monitor your environment.


It's widely used in GMP Controlled Areas, Isolators, Restricted Access Barrier Systems (RABS), Cleanrooms, Hospital Pharmacies, Laboratories, Industrial, Aerospace, Trend Analysis, Clean Micro-environment Monitoring, Multi-spot Monitoring, etc.
