Zetron FIT-600 Filter Integrity Tester Confident filterintegrity testing forcritical processes
Zetron FIT-600 Filter Integrity Tester Confident filterintegrity testing forcritical processes
Zetron FIT-600 Filter Integrity Tester Confident filterintegrity testing forcritical processes
Zetron FIT-600 Filter Integrity Tester Confident filterintegrity testing forcritical processes
Zetron FIT-600 Filter Integrity Tester Confident filterintegrity testing forcritical processes
Zetron FIT-600 Filter Integrity Tester Confident filterintegrity testing forcritical processes
Specifications
Sensitivity :
forward flow: 0.1ml/min water immersion: 0.01ml/min bubble point: 50mbar
MOQ :
1
Delivery Time :
1-10 work days
Dimension :
40cm(width) x30cm(depth) x 25cm(height)
Price :
USD 5000-10000 set
Packaging Details :
Carton size : 99.45 *48.2 mm
Power supply/power :
170-240V AC, 50/60Hz 100W
Model Number :
FIT-600
Payment Terms :
T/T,Western Union,MoneyGram,D/P,D/A,L/C
Supply Ability :
1000 SET / week
Product name :
FIT-600 Filter Integrity Tester
Brand Name :
Zetron
Maximum operating pressure :
10000 mbar
Certification :
CE
Minimum inlet pressure :
100 mbar
Place of Origin :
China
Description
Zetron FIT-600 Filter Integrity Tester Confident filterintegrity testing forcritical processes
OVERVIEW

FIT-600 verifies filter accuracy, membrane condition and assembly leak-tightness. Microprocessor control guides six test programs, displays live pressure curves and stores results for review, printing and PDF export.

Zetron FIT-600 Filter Integrity Tester Confident filterintegrity testing forcritical processes

FEATURES & BENEFITS
  • High intelligence: the test process is fully automatically controlled, without manual intervention;
  • High reliability: high detection accuracy and good reproducibility;
  • High user-friendly: touch screen input, friendly operation interface;
  • Multi-function: can be used to test single-core filters, multi-core filters, and multiple test functions;
  • High integration: the instrument adopts a portable design, small size, and easy to use;
  • High-tech: uses ARM11 controller and Windows CE 6.0 system;
  • High practicality: data storage and real-time printing of test results, in line with GMP requirements.
APPLICATION
  • Disc membrane: various membranes from Φ25mm to Φ300mm
  • Standard cartridge: 2.5″ to 40″, 1 to 9 cores
  • Capsule
  • Mini cartridge
  • Air filter testing 2.5″ to 40″ other parameter cartridges

Zetron FIT-600 Filter Integrity Tester Confident filterintegrity testing forcritical processes

PRODUCT PARAMENTERS
Model FIT-600
Test programs 6 automatic methods
Control Microprocessor-controlled
Display Backlit English touchscreen
User access Four role-based levels
Power supply 100–240 VAC, 50/60 Hz
Operating temperature 5–40 °C
Relative humidity 10–80% RH, non-condensing
Ingress protection IP42
Supply gas Dry, clean, oil-free air or nitrogen
