Honeycomb Ceramics for Ladle Preheaters with 30-50% Fuel Savings and 60-80% Faster Preheating Using 1100°C Preheated Air
Honeycomb Ceramics for Ladle Preheaters with 30-50% Fuel Savings and 60-80% Faster Preheating Using 1100°C Preheated Air
Honeycomb Ceramics for Ladle Preheaters with 30-50% Fuel Savings and 60-80% Faster Preheating Using 1100°C Preheated Air
Honeycomb Ceramics for Ladle Preheaters with 30-50% Fuel Savings and 60-80% Faster Preheating Using 1100°C Preheated Air
Honeycomb Ceramics for Ladle Preheaters with 30-50% Fuel Savings and 60-80% Faster Preheating Using 1100°C Preheated Air
Honeycomb Ceramics for Ladle Preheaters with 30-50% Fuel Savings and 60-80% Faster Preheating Using 1100°C Preheated Air
Honeycomb Ceramics for Ladle Preheaters with 30-50% Fuel Savings and 60-80% Faster Preheating Using 1100°C Preheated Air
Honeycomb Ceramics for Ladle Preheaters with 30-50% Fuel Savings and 60-80% Faster Preheating Using 1100°C Preheated Air
Specifications
Place of Origin :
China
Price :
Negotiable
Usage :
Industry Usage
Chemical Composition :
Al2O3, SiO2
Sic Content :
85%
Maximum Temperature :
1600℃
Characteristics :
High wear resistance
Thermal Expansion Coefficient :
4.0-4.5 × 10^-6 /K
Material Composition :
4%Si >96%Sic
Working Temperature :
1650
Advantage :
Wear and abrasion resistance
Purity :
98%
Material :
Silicon Carbide Ceramic
Acid Alkaline Proof :
excellent
Solubility :
Insoluble
Open Porosity :
<0.1%
Flexural Strength :
350-550 MPa
Packaging Details :
Strong wooden box for Global shipping
Model Number :
Customizable
Delivery Time :
Negotiable
Brand Name :
KEGU
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
MOQ :
Negotiable
Description
Honeycomb Ceramics for Ladle/Tundish Preheaters: Efficiency Redefined
Cut fuel costs by 30-50% and slash preheating time by 60-80% with our advanced regenerative honeycomb ceramic solutions.
Core Advantages: Why Choose Our Honeycomb Ceramics?
Our honeycomb ceramic regenerators are engineered specifically for the demanding environment of ladle and tundish preheaters, delivering unmatched performance through regenerative combustion technology.
  • Dramatic Energy Savings: Preheats combustion air to over 1100°C, enabling efficient use of low-cost fuels. Recovers waste heat to exhaust at ~150°C, reducing fuel consumption by 30-50%.
  • Faster, More Uniform Heating: Achieves higher flame temperatures for superior heat transfer, cutting preheating time by 60-80%. Eliminates hot spots, ensuring even temperature distribution and extending refractory lining life by 15% or more.
  • Greener Operation: Promotes complete combustion, lowering CO and NOx emissions by over 50% to meet strict environmental standards.
How It Works: The Regenerative Cycle
The system uses paired ceramic regenerators that continuously alternate between two functions in a fast cycle (typically 20-60 seconds):
  • Heat Capture: Hot exhaust gases pass through one regenerator, transferring their heat to the honeycomb structure.
  • Heat Release: Cold combustion air is then directed through the hot regenerator, absorbing the stored heat before entering the burner.
This creates a highly efficient, self-sustaining loop of energy recovery.
Key Performance & Specifications
Max. Working Temperature ≥1200°C
Preheating Time ~10 min (Hot Turnaround) / ~30 min (Standard)
Control & Safety Auto-ignition, flame monitoring, safety shut-off, temperature display & alarms
Recommended Material Cordierite-Mullite (balanced performance) or Mullite/Corundum-Mullite (extreme temperature)
Standard Block Size 150*150*300 mm
The Result: Clear Performance Upgrade
Performance Metric Traditional Preheater Our Regenerative Preheater
Fuel Efficiency Baseline 30-50% Better
Cycle Time Baseline 60-80% Faster
Temperature Uniformity Poor Excellent (±50°C)
Lining Life Baseline 15%+ Longer
Emissions Baseline 50%+ Lower
Ideal For:
  • Steel mills aiming to reduce energy costs and carbon footprint.
  • Operations using low-calorific-value gases (e.g., blast furnace gas).
  • Facilities requiring faster ladle turnaround or more uniform preheating.
  • Plants needing to meet stringent environmental regulations.

Ready to redefine your preheating efficiency? Contact our engineering team today for a customized solution that fits your specific ladle and tundish needs.
