Sustainable C Beam Steel Precision Engineered C Shaped Steel Solar Mounting Rail
Sustainable C Beam Steel Precision Engineered C Shaped Steel Solar Mounting Rail
Sustainable C Beam Steel Precision Engineered C Shaped Steel Solar Mounting Rail
Sustainable C Beam Steel Precision Engineered C Shaped Steel Solar Mounting Rail
Sustainable C Beam Steel Precision Engineered C Shaped Steel Solar Mounting Rail
Sustainable C Beam Steel Precision Engineered C Shaped Steel Solar Mounting Rail
Specifications
Certification :
ISO 9001:2015
Delivery Time :
15-25 days after deposit
Packaging Details :
Steel pallet with protective film and export-grade strapping
Flange Width :
50 mm
Brand Name :
ECER
Supply Ability :
200000 Pieces per Month
Material :
Q235B / Q355B Carbon Steel
Beam Height :
100 mm
Wall Thickness :
2.0-3.0 mm
Model Number :
CB-100X50
Payment Terms :
T/T, L/C, Western Union
Tolerance :
ASTM A653 / EN 10346
Price :
USD 3.5-8.5 / Piece
Surface Treatment :
Hot Dip Galvanized
Warranty :
25 Years Structural
MOQ :
500 Pieces
Standard Length :
3000 mm / 6000 mm or customized
Place of Origin :
Guangdong, China
Description
Sustainable C Beam Steel Precision Engineered C Shaped Steel Solar Mounting Rail
The Sustainable C Beam Steel is a precision engineered structural profile developed for modern solar mounting and lightweight structural applications. Manufactured from recycled-content Q235B and Q355B carbon steel, this C shaped steel rail combines an outstanding strength-to-weight ratio with a fully recyclable construction, allowing project owners to reduce embodied carbon without compromising load performance or service life.
Every C beam steel section is roll-formed on computer-controlled production lines and then hot-dip galvanized to deliver uniform coating thickness, straightness and dimensional consistency. The open C shaped steel geometry simplifies bolting, cable routing and rail splicing on site, which shortens installation time for both ground-mounted and roof-mounted photovoltaic systems. The result is a durable, cost-effective rail that performs reliably in demanding outdoor environments.
Key Features
  • Sustainable Material Selection: Recycled-content carbon steel and fully recyclable design reduce embodied carbon, supporting green building targets and environmentally responsible solar projects.
  • Precision Engineered Profile: Computer-controlled roll forming produces consistent beam height, flange width and wall thickness so every section aligns cleanly during assembly.
  • Corrosion Resistant Coating: Hot-dip galvanizing forms a metallurgical barrier that resists rust, humidity and salt-laden air, extending service life in coastal and industrial sites.
  • High Load Capacity: Optimized C shaped geometry carries heavy module and wind loads while keeping steel weight low, reducing foundation and transport costs.
  • Easy Site Fabrication: Pre-punched options and clean edges permit fast cutting, drilling and bolting, cutting labour time on large utility-scale installations.
  • Long Service Life: A 25-year structural warranty backs the galvanized finish, giving engineers long-term confidence in critical mounting structures.
Technical Specifications
Parameter Specification
Material Grade Q235B / Q355B carbon steel
Surface Treatment Hot dip galvanized, 80 µm average
Beam Height 100 mm
Flange Width 50 mm
Wall Thickness 2.0 mm / 2.5 mm / 3.0 mm
Standard Length 3000 mm or 6000 mm, customized on request
Tolerance Standard ASTM A653 / EN 10346
Service Life 25 years structural warranty
Applications
Sustainable C beam steel rails are widely used as purlins, module support rails and cable management profiles in ground-mounted solar farms, commercial rooftop arrays and solar carports. Because the profile accepts standard bolts and clamps, it adapts quickly to different module sizes, mounting angles and array layouts. Engineers also specify this rail for light structural framing, equipment supports and general fabrication where a straight, galvanized and recyclable section is required.
Packaging & Quality Assurance
Each C beam steel bundle is stacked on a steel pallet, wrapped with protective film and secured with export-grade strapping to prevent scratches and deformation during ocean freight. Before shipment every batch is checked for length, hole position, coating thickness and straightness in line with ISO 9001:2015 procedures. Mill certificates and galvanizing reports are supplied on request so buyers can verify material and finish quality.
