MICRO-D Rectangular Connectors , CRM-232-010-111-8401
MICRO-D Rectangular Connectors , CRM-232-010-111-8401
MICRO-D Rectangular Connectors , CRM-232-010-111-8401
MICRO-D Rectangular Connectors , CRM-232-010-111-8401
MICRO-D Rectangular Connectors , CRM-232-010-111-8401
MICRO-D Rectangular Connectors , CRM-232-010-111-8401
MICRO-D Rectangular Connectors , CRM-232-010-111-8401
MICRO-D Rectangular Connectors , CRM-232-010-111-8401
Specifications
Brand Name :
HIGH WOOD
Model Number :
CRM-232-010-111-8401
Certification :
AS9001
Place of Origin :
China
MOQ :
100PCS
Price :
10＄--150＄
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100,000pcs per month
Delivery Time :
2--9 weeks
Packaging Details :
standard export package
Operating temperature :
-55℃~+125℃
Rated current :
3A
Mating times :
1000 cycle
Contact resistance :
≤25mΩ
Impact :
Acceleration 980m/s 2
Locking attachment :
Stainless steel
Insulator :
PPS
Inner conductor :
The copper alloy is plated with gold
Description

CRM SERIES MICRO-D Rectangular Connectors, CRM-232-010-111-8401

THE CRM SERIES CONNECTOR FEATURES:

Technical characteristics
Ambient temperature
-55℃~+125℃
Vibration
10Hz~2000Hz 147m/s 2
Impact
 Acceleration 980m/s 2
Electrical performance index
Dielectric withstand voltage
750V(Standard atmosphere) 250V(Low atmospheric pressure)
Insulation resistance
≥5000MΩ(Normal temperature) ≥20MΩ (Damp and hot)
Contact resistance
≤25mΩ
Rated current
 3A
Mechanical performance index
Mechanical life
 1000 times
Material and coating
Locking attachment
 Stainless steel
Insulator PPS
Inner conductor The copper alloy is plated with gold

Product show:

MICRO-D Rectangular Connectors , CRM-232-010-111-8401MICRO-D Rectangular Connectors , CRM-232-010-111-8401MICRO-D Rectangular Connectors , CRM-232-010-111-8401MICRO-D Rectangular Connectors , CRM-232-010-111-8401

Drawings show:

MICRO-D Rectangular Connectors , CRM-232-010-111-8401
