M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
Specifications
Payment Terms :
T/T, L/C, Western Union
Conductor Resistance :
≤ 5 mΩ
Ambient Temperature :
-40℃ ~ +90℃
Model Number :
M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
Rated Voltage :
30V
Packaging Details :
Standard export package
MOQ :
100pcs
Delivery Time :
2-9weeks
Price :
5＄--50＄
Insulation Resistance :
≥100 MΩ
Supply Ability :
100，000pcs per month
Rated Current :
1.5A
Certification :
AS9001
Brand Name :
HIGH WOOD
Place of Origin :
China
Description

M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A

Product Features:

1.Threaded locking mechanism, shock-resistant locking design, 12mm threaded connector; Vertical solder cup soldering, unshielded design, injection-molded,structurally robust; resistant to vibration and tension

2.Quick plug-and-play, withstands repeated plug-and-unplug cycles, simple and convenient installation;Suitable for industrial sensors and fieldbus signal connections

Product Specifications:

Electrical Performance
Rated Current 5A
Rated Voltage 250V AC/rms 50Hz
Withstanding Voltage 1000V AC/rms 50Hz for one minute
Insulation Resistance 1000MΩ at 500V DC
Contact Resistance 20mΩ max
Mechanical Performance
Single Contact Insertion Force 1.19 lbs (0.54kg) max
Single Contact Extraction Force 0.13 lbs (0.06 kg) min
Mating Cycles ≥500 cycles
Environmental Performance
Operating Temperature -55 ~ 125℃

Product showing:

M12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code AM12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code AM12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code AM12 Connector, 5-Pin Injection-Molded Male, Straight Solder Cup, No Shielding, Code A
