M5 Series Straight Waterproof 4-core Female Receptacle
M5 Series Straight Waterproof 4-core Female Receptacle
M5 Series Straight Waterproof 4-core Female Receptacle
M5 Series Straight Waterproof 4-core Female Receptacle
M5 Series Straight Waterproof 4-core Female Receptacle
M5 Series Straight Waterproof 4-core Female Receptacle
M5 Series Straight Waterproof 4-core Female Receptacle
M5 Series Straight Waterproof 4-core Female Receptacle
Specifications
Payment Terms :
T/T, L/C, Western Union
Single contact insertion force :
Max 1.19 lb (0.54 kg)
Model Number :
M5 Series Straight Waterproof 4-core Female Receptacle
Rated Current :
5A
MOQ :
100pcs
Delivery Time :
2-9weeks
Insulation Resistance :
1000MΩ at 500V DC
Service Life :
≥500 cycles
Packaging Details :
Standard export package
Price :
5$-50$
Contact Resistance :
Max 20mΩ
Supply Ability :
50，000pcs per month
Single contact withdrawal force :
Min 0.13 lb (0.06 kg)
Certification :
AS9001
Rated Voltage :
250V AC/rms 50Hz
Brand Name :
HIGH WOOD
Place of Origin :
China
Withstand Voltage :
1000V AC/rms 50Hz for one minute
Description

M5 Series Straight Waterproof 4-core Female Receptacle

Product Introduction:

The M5 straight waterproof female connector belongs to the M series of miniature circular sensor connectors, featuring a threaded locking mechanism and a rear-mounting plate design. It is a specialized aviation connector designed for sensor signal transmission in compact devices. With its threaded locking structure, the connector is mounted on equipment panels to ensure stable signal connection, offering excellent waterproof performance, a small and compact size, and suitability for tight installation spaces.

Specifications:

Category Item Specification
Electrical Performance Rated Current 5A
Rated Voltage 250V AC/rms 50Hz
Withstand Voltage 1000V AC/rms 50Hz for one minute
Insulation Resistance 1000MΩ at 500V DC
Contact Resistance Max 20mΩ
Mechanical Performance Single contact insertion force Max 1.19 lb (0.54 kg)
Single contact withdrawal force Min 0.13 lb (0.06 kg)
Service Life ≥500 cycles
Environmental Performance Temperature Range -55 ~ 125℃

Product pictures:


M5 Series Straight Waterproof 4-core Female ReceptacleM5 Series Straight Waterproof 4-core Female ReceptacleM5 Series Straight Waterproof 4-core Female ReceptacleM5 Series Straight Waterproof 4-core Female Receptacle
