Specifications
Payment Terms :
T/T, L/C, Western Union
Ambient Temperature :
-60°C～+100℃
Contact diameter :
⌀1.0mm
Supply Ability :
100，000pcs per month
Connector type :
PM4 Series Russian standard connector
Model Number :
HW-PM4-32-1K6B
Working hours :
1000 hours(min)
MOQ :
100pcs
Delivery Time :
2-9weeks
Insertion and removaltimes :
1000 times
Contact resistance :
≤5mΩ
Vibration :
1-2000HZ 30g
Certification :
AS9001
Place of Origin :
China
Price :
10$-150$
Insulation Resistance :
≥1000MΩ
Brand Name :
HIGH WOOD
Technical conditions :
TEO.364.196TY
Packaging Details :
Standard export package
Description

Russian standard connector HW-PM4-32-1K6B

Product introduction

Russian Military Standard Electric Connector HW-PM4-32-1K6B electric connector is used in AC/DC circuit, in accordance with Russian technical conditions Russian Military Standard Electric Connector HW-PM4-32-1K6B.

Domestic model :PM4

Main Technical Parameters

Russian Military Standard Electric Connector HW-PM4-32-1K6B

Mark specification

Russian Military Standard Electric Connector HW-PM4-32-1K6B

Insulator hole group arrangement (hole front view)

Russian Military Standard Electric Connector HW-PM4-32-1K6B

Product pictures:

Russian Military Standard Electric Connector HW-PM4-32-1K6BRussian Military Standard Electric Connector HW-PM4-32-1K6BRussian Military Standard Electric Connector HW-PM4-32-1K6BRussian Military Standard Electric Connector HW-PM4-32-1K6B
