HW-M55-7106842R 1.27mm (0.05) Pitch PCB Horizontal SMT Connector
HW-M55-7106842R 1.27mm (0.05) Pitch PCB Horizontal SMT Connector
HW-M55-7106842R 1.27mm (0.05) Pitch PCB Horizontal SMT Connector
HW-M55-7106842R 1.27mm (0.05) Pitch PCB Horizontal SMT Connector
HW-M55-7106842R 1.27mm (0.05) Pitch PCB Horizontal SMT Connector
HW-M55-7106842R 1.27mm (0.05) Pitch PCB Horizontal SMT Connector
HW-M55-7106842R 1.27mm (0.05) Pitch PCB Horizontal SMT Connector
HW-M55-7106842R 1.27mm (0.05) Pitch PCB Horizontal SMT Connector
Specifications
Brand Name :
HIGH WOOD
Model Number :
HW-M55-7106842R
Certification :
AS9001
Place of Origin :
China
MOQ :
100PCS
Price :
10＄--150＄
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100,000pcs per month
Delivery Time :
2--9 weeks
Packaging Details :
standard export package
Connection Type :
Surface Mount (SMT)
Connector Orientation :
Horizontal
Number of Rows :
2
Number of Signal Contacts :
68
Operating temperature :
-55 ℃ - 125 ℃
Current Rating :
1.2A max per contact
Finish / Plating on Contact Surface :
Gold
Description

HW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT Connector

HW-M55-7106842R

PRODUCT DESCRIPTION

  • Double Row Surface Mount, 10mm total footprint depth, shrouded polarized connector – 68 contacts (34+34). Location pegs, surface mount hold-down retaining tabs for additional solder strength.
  • Board stacking connectors for 90 degree or coplanar board-to-board connection. Supplied in Tape and Reel. Gold finish on contact area, Tin finish on termination.

SPECIFICATION

Contact Pitch:

1.27mm (0.05")

Contact Gender:

Male/Plug

Connector Orientation:

Horizontal

Connection Type:

Surface Mount (SMT)

Current Rating:

1.2A max per contact

Operating Temperature:

-55°C to +125°C

Soldering Data:

Max Solder Temperature: 260°C for 10 seconds

Polarising Features:

Yes

End Stackable:

No

Side Stackable:

No

Can be cut to another size:

No

Number of Rows:

2

Number of Signal Contacts:

68

MATERIALS

Finish / Plating on Termination:

100% Tin over Nickel

Finish / Plating on Contact Surface:

Gold

Base Material of Contact:

Phosphor Bronze

Housing Material:

LCP

Housing Colour:

Black

Housing Material UL Rating:

UL94V-0
