Specifications
Brand Name :
HIGH WOOD
Model Number :
J599A8（ARINC801）
Certification :
AS9001
Place of Origin :
China
MOQ :
100pcs
Price :
10$-150$
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
100，000pcs per month
Delivery Time :
2-9weeks
Packaging Details :
Standard export package
Plating :
Stainless steel passivation
Type of connector :
Plug
Temperature :
-55℃ ~ +125℃
Endurance :
500 cycles
Insertion loss :
≤0.6dB
Salt spray :
500h
Description

J599A8(ARINC801)

  • The interface size conforms to GJB599B(MIL-DTL-38999) Ⅲ series, and the performance conforms to ARINC801 standard
  • Suitable for aeronautical, electronic, shipboard and other systems for multi-channel optical communication
  • Adopts standard 1.25mm ceramic pin for high docking accuracy
  • Ceramic casing package array, can be disassembled and replaced as a whole, easy to use and maintain
  • Install and remove tool M81969/14-03 for contact parts, easy to operate

How to order:

J599A8（ARINC801）series optical fiber connector，

Product pictures:

J599A8（ARINC801）series optical fiber connector，J599A8（ARINC801）series optical fiber connector，J599A8（ARINC801）series optical fiber connector，

Environmental:

Temperature :

-55℃ ~ +125℃

Salt spray:

ClassK,W:500h

ClassF:48h

Class MW: 192h (acidic atmosphere)
Air tightness (suitable for airtight switching socket): gas leakage rate ≤1×10-9Pa.m3/s, internal
and external pressure difference of 1 atmosphere

Mechanical:

Tensile force:: ≥68N (2mm contact jumper)
Endurance: 500 cycles
Vibration:

10Hz ~ 2000Hz, powerspectral density 0.4G²/Hz, acceleration
root mean square value 23.1G
Impact: Peak acceleration 2940m/s²,duration 3ms,Velocity change rate5.61m/s

Optical performance​:

Insertion loss: ≤0.6dB
RL (return loss): ≥ 20dB@850nm；
≥ 40dB@1310nm

Plug dimensions:

J599A8（ARINC801）series optical fiber connector，

Contact arrangement (take plug surface as an example):

J599A8（ARINC801）series optical fiber connector，

17-08
