40kV 10000pF High Voltage Ceramic Capacitor 80x22mm
40kV 10000pF High Voltage Ceramic Capacitor 80x22mm
40kV 10000pF High Voltage Ceramic Capacitor 80x22mm
40kV 10000pF High Voltage Ceramic Capacitor 80x22mm
40kV 10000pF High Voltage Ceramic Capacitor 80x22mm
40kV 10000pF High Voltage Ceramic Capacitor 80x22mm
Specifications
Brand Name :
XIWUER
Model Number :
40kV-10000pF
Certification :
ISO9001,ISO14001,OHSAS18001
Place of Origin :
XIAN, SHANNXI CHINA
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
4,000,000 pcs a year
Delivery Time :
10-15 days
Packaging Details :
Carton
Dissipation :
≦0.0040
Withstanding voltage :
1.5Ur● 1min
Insulation resistance :
≧1.0×105MΩ
Dimension(mm) :
D:80 | H:22 | L:26 | D:16 | M:5
Description
40kV 10000pF High Voltage Ceramic Capacitor
Product Overview

Ultra-high voltage ceramic capacitors are essential components for specialized industrial applications, offering high withstand voltage, low loss, and exceptional performance in high peak current and rapid pulse discharge scenarios.

40kV 10000pF High Voltage Ceramic Capacitor 80x22mm

Key Applications
  • Pulse power and laser equipment
  • Medical imaging systems
  • Industrial processing machinery
  • Power transmission and energy infrastructure
  • Scientific research and specialized industrial applications
Technical Specifications
No. Specification Dissipation Withstanding Voltage Insulation Resistance Dimensions (mm)
1 20kV-2000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:45 | H:19 | L:23 | D:12 | M:5
2 20kV-10000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:65 | H:15 | L:19 | D:12 | M:5
3 20kV-18000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:80 | H:17 | L:25 | D:12 | M:5
4 30kV-1000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:45 | H:24 | L:32 | D:12 | M:4
5 30kV-2700pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:60 | H:20 | L:28 | D:12 | M:4
6 30kV-12000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:45 | H:19 | L:23 | D:12 | M:5
7 40kV-150pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:74 | H:18 | L:26 | D:12 | M:5
8 40kV-500pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:28 | H:33 | L:41 | D:8 | M:4
9 40kV-7500pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:80 | H:24 | L:29 | D:12 | M:6
10 40kV-10000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:80 | H:22 | L:26 | D:16 | M:5
Selection Guidelines

High-voltage ceramic capacitors require careful selection and handling. Consider these critical factors:

  • Voltage Margin: Operating voltage must be significantly below rated voltage, accounting for peak pulse conditions
  • Thermal Management: Proper heat dissipation is essential for high-frequency/high-current applications
  • Frequency Characteristics: Performance varies by dielectric material - consult detailed specifications
  • Safety Compliance: All design, installation and operation must follow strict safety regulations by qualified personnel
Product Certifications
40kV 10000pF High Voltage Ceramic Capacitor 80x22mm 40kV 10000pF High Voltage Ceramic Capacitor 80x22mm 40kV 10000pF High Voltage Ceramic Capacitor 80x22mm
