Specifications
Model Number :
MYS5-385/20-2P（NS）
Price :
Negotiable
SPD according to IEC 61643-11 :
Class II
Installation Location :
Indoor
Delivery Time :
25~30 days
Nominal Discharge Current (In) :
20kA (8/20μs)
Operating Temperature Range :
-40℃ ~ +70℃
Housing Material :
Thermoplastic, UL94 V-0
Voltage Protection Level (Up) :
≤1.9kV
Minimum Conductor Cross Section :
1.5mm² Solid Wire / Flexible Wire
Mounting Method :
35mm DIN Rail, EN 60715
Brand Name :
XIWUER
MOQ :
100
SPD according to EN 61643-11 :
Class 2
Protection Degree :
IP20
Operating Status / Fault Indication :
Green / Red
Bolt Type / Torque :
M5 / 3.0Nm ±10%
Place of Origin :
China
Supply Ability :
3,000,000 pcs a year
Maximum Continuous Operating Voltage (Uc) :
385V AC, 50/60Hz
AC Switching Capacity :
125VAC/1A
Cross-sectional Area of Remote Signaling Terminal :
0.2mm²
Screw Hole Type / Torque :
M2/0.25Nm
Packaging Details :
Carton
Maximum Discharge Current (Imax) :
40kA (8/20μs)
Maximum Conductor Cross Section :
35mm² Stranded Wire / 25mm² Flexible Wire
Response Time (ta) :
≤25ns
Number of Ports :
1
Remote Signaling Contact Type :
Floating Changeover Contact
Certification :
ISO9001,ISO14001,ISO45001,CCC
Payment Terms :
L/C,T/T
AC Nominal Voltage (Un) :
230V AC, 50/60Hz
DC Switching Capacity :
30VDC/0.5A
Description

Product Description

The MYS5-385/20-2P Surge Protective Device (SPD) is designed for overvoltage protection in low-voltage AC power distribution systems.

It is used to protect electrical equipment from transient overvoltage caused by lightning surges, switching operations, and other electrical disturbances.

This Type 2 SPD complies with EN 61643-11 Class II and IEC 61643-11 Class II standards. It features a 385V AC maximum continuous operating voltage (Uc), 20kA nominal discharge current (In), and 40kA maximum discharge current (Imax), providing reliable surge protection performance.

The device adopts a 35mm DIN rail mounting design, suitable for installation in distribution cabinets, control panels, and other indoor electrical systems.


Product Features

  • Type 2 / Class II surge protective device
  • Nominal discharge current: 20kA (8/20μs)
  • Maximum discharge current: 40kA (8/20μs)
  • Maximum continuous operating voltage: 385V AC
  • Low voltage protection level: ≤1.9kV
  • Fast response time: ≤25ns
  • DIN rail mounting according to EN 60715
  • Operating temperature: -40℃ to +70℃
  • Green/red status indicator for operation and fault monitoring
  • UL94 V-0 flame-retardant thermoplastic housing

Applications

The MYS5-385/20-2P SPD is suitable for:

  • Low-voltage power distribution systems
  • Electrical distribution cabinets
  • Industrial control systems
  • Building electrical installations
  • Automation equipment protection
  • Indoor power supply protection systems
