Specifications
Brand Name :
Hightop
Model Number :
HTS380
Certification :
CE，EPA，ISO，TUV
Place of Origin :
China
MOQ :
1 Set
Payment Terms :
L/C,D/A,T/T,D/P,Western Union,MoneyGram
Supply Ability :
100 set per month
Delivery Time :
5-14 work days
Packaging Details :
Wooden case
Product name :
Skid steer loader
Max pin height :
1856mm
Wheelbase :
636 mm
No bucket length :
1752 mm
Total width :
1033 mm
Description

Advantage:
The HT380mini skid steer is equipped with a Briggs & Stratton engine for high load capacity. The dual joystick control is easy to operate, and the machine is multi-purpose, allowing you to replace various attachments such as de-icer, snow pusher, sweeper, hedge trimmer and so on.

Feature:
1.Famous Brand Engines Outstanding quality.
Rating Horsepower: 23hp,Kubota® diesel engine .
Engine brand : Briggs & Stratton, RATO, LONCIN Gasoline engines and Kubota diesel engine, Kholer.
World Top Powerful and Reliable Kubota® diesel engine provides exceptional power.
2.Imported Motors
Optimized hydraulics deliver the smoothest ride in the industry, allowing operators to stay comfortable and productive for long hours on the job.
3.Multifunctional equipment
The machine is equipped with an advanced attachment locking system for simple and safe connection Italian brand FASTER quick coupling, which can quickly connect several accessories to achieve different jobs, one machine is multi-purpose, with forklifts, excavators, trenchers, augers , cultivators, sweepers, snow blowers, excavators, drilling machines, crushers have the same functions.
4.Flexible convenient operation
Ergonomic operator's station comes standard with dual-level ground drive controls, with an optional joystick,allowing the operator to control each track independently for improved maintenance an mobility on difficult jobsite conditions.

Model:HTS380

Max working height

2115 mm

Max pin height

1856 mm

Max dump height

1460 mm

The highest point discharge distance

388 mm

Bucket swing angle

55°

Bucket unloading angle

30°

Opening-closing angle

25°

Angle of departure

8°

Total height

1205 mm

The height from the ground

90 mm

Wheelbase

636 mm

No bucket length

1752 mm

Total width

1033 mm

Bucket width

980 mm

Total length(with bucket)

2206 mm

Turning radius

1307 mm
