Automatic Loading Adhesive Tape Coating Machine 1100mm Web Width Support
Automatic Loading Adhesive Tape Coating Machine 1100mm Web Width Support
Specifications
Brand Name :
TURUI
Model Number :
TBA-G
Certification :
CE
Place of Origin :
Made in China
MOQ :
1set
Price :
Negotiable
Supply Ability :
5-10 sets / month
Delivery Time :
2-3 months
Packaging Details :
Wooden packages/ seaworthy packing
Material :
Steel
Origin :
Made in China
Payment terms :
LC / TT
Packing :
Wooden packages / Seaworthy packing
Port of loading :
Guangdong
Web Width :
1100mm
Speed :
80m/min
Substrate :
BOPP film
Description

TBA-G High Adhesive Tape Coating Machine / Multi-functional Coating Machine

Application:subitable for release paper, adverstising consumables, crepe paper, lable paper, double sided tape, cloth tape, reflective cloth, reflective film., ect, coating.

Feature of this adhesive tape coating machine:

1. Motor: 2 motor with inverters speed adjusting

2. Printing: 1-2 colors gravure printing

3. Coating: comma blade Transfer coating, making different coating thickness on same machine.

4. Temperature: Segmented temperature control. when the temperature reach the set figure , it will auto stop heating . same for auto heating .

5. Slitting: 4 rewinding shafts for making tapes .& jumbo roll rewinding shaft for making jumbo roll.

6. EPC: Sensitive infrared ray can monitor the film walking in right rewinding direction.

so the tape rewinding edge will be flat & nice.

Specification:

Model 600 1100 1450 1700
Web Width 600mm 1100mm 1450mm 1700mm
Mechanical speed 5-40m/min 5-80m/min 50-80m/min 50-80m/min
Glue uniformity ±0.001mm
Rewinding evenness ±1mm
Heating method Steam / Hot air / Thermal oil / Electricity
Drying length According to customer requirement
Power 380V 50HZ
Air source 5-7kgcm2
