70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
Specifications
Brand Name :
PULLNER
Model Number :
PHFZ
Certification :
ISO19001/ISO14001/ISO54001
Place of Origin :
SHANGHAI, CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C,T/T,D/A,D/P,Western Union
Supply Ability :
2000pcs per week
Delivery Time :
7-12 work days
Packaging Details :
Customized wooden carton after poly bag
Description
70inch Condense Water PP Pleated Filter Cartridge

PHFZ Series pleated filter cartridges feature PP pleated filtration media with thermal melting welding construction. Designed for multiple backwashing cycles and iron removal in power generation condensate water systems. Available in various configurations for both start-up and operating filtration requirements.

Product Applications
  • Pre-filter protection to prevent premature fouling of RO membranes
  • Boiler condensate filtration for nuclear and fossil fuel power plants
  • Heat recovering steam generators and combined cycle plants
  • Pre-RO filtration systems
Product Specifications
Series Media Micron Length Structure Connection Thread End Thread
PHFZ PP=Polypropylene 0100=1.0μm
0400=4.0μm
1000=10μm		 60=60"
70=70"		 I=7Part(φ69)
II=4+3(φ65)
III=3+1(φ69)		 Z1=1 1/2"-12
Z2=M33*1.5		 W1=M8
W2=M10
W3=M6
W4=3/8
Technical Specifications
Filter Media Polypropylene (PP)
Cage/Core/End cap Polypropylene (PP)
Accessories (nut, screw) SS304
Maximum Operating Temperature 85℃
Maximum Operating Differential Pressure 3.0bar/65℃
Filtration Area 6.5m²
Flow Rate (Design) 3.5-4.5m³/h
Flow Rate (Recommend) 3.9m³/h
Inlet Water Quality <2000ppb
Alternative Flow Rate (Design) 2.2-2.8m³/h
Alternative Flow Rate (Recommend) 2.5m³/h
Recommended Inlet Water Quality <1000ppb
Certification
70inch PP Pleated Filter Cartridge for Condense Water in Power Plants 70inch PP Pleated Filter Cartridge for Condense Water in Power Plants 70inch PP Pleated Filter Cartridge for Condense Water in Power Plants
Frequently Asked Questions
Q1: What is your brand name?
A1: Our brand name is PULLNER.
Q2: What is the model number of your High Flow Filter Cartridge?
A2: The model number of our High Flow Filter Cartridge is PHFZ.
Q3: Where is your High Flow Filter Cartridge manufactured?
A3: Our High Flow Filter Cartridge is manufactured in China, Shanghai.
Q4: What kind of filtration performance can your High Flow Filter Cartridge provide?
A4: Our High Flow Filter Cartridge provides high filtration efficiency, low initial pressure drop, and extended service life.
Q5: What are the advantages of your High Flow Filter Cartridge?
A5: Our High Flow Filter Cartridge offers high filtration accuracy, superior dirt-holding capacity, and cost-effective operation.
