Specifications
Brand Name :
PULLNER
Model Number :
PBT Series
Certification :
FDA/ISO 9001/ISO 14001
Place of Origin :
SHANGHAI,CHINA
MOQ :
10 PCS
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
50 PCS per week
Delivery Time :
1 Month
Packaging Details :
Individual packaged in carton box after poly bag.
Description
60-Inch Length PBT Series All Polyester Filter Cartridge
The PBT series filter cartridge is constructed entirely from Polyester (PET) material, specifically designed for precision filtration of liquids containing aromatic hydrocarbon solvents such as benzene and toluen-e. This all-polyester construction provides excellent temperature and pressure resistance, capable of withstanding 120℃ high temperatures for extended periods and operating at 4 bar differential pressure.
Technical Specifications
Filtration Rating 0.2μm, 0.45μm, 1μm, 5μm, 10μm, 25μm, 50μm
Maximum Operating Temperature 120℃
Maximum Operating Differential Pressure 4bar/21℃, 2.4bar/80℃
Filter Media Polyester (PET)
Support/Drainage Polyester (PET)
Cage/Core/End Caps Polyester (PET)
Seal Material EPDM, Silicone, V, FEP
Chemical Compatibility
Chemical Compatibility
Benzene R (Resistant)
Xylene R (Resistant)
Aceton-e R (Resistant)
Trichloroethylene R (Resistant)
CCl4 R (Resistant)
Tetrahydrofuran R (Resistant)
Gasoline NR (Not Resistant)
Acid NR (Not Resistant)
Ordering Information
Series Micron Rating Length End Cap Type Seal Material
PBT 0020 = 0.2μm 05 = 5" C1 = 226/Spear E = EPDM
0045 = 0.45μm 10 = 10" C3 = 222/Spear S = Silicone
0100 = 1.0μm 20 = 20" C5 = 222/Flat V = V
0500 = 5.0μm 30 = 30" C6 = 226/Flat P = FEP
1000 = 10μm 40 = 40" C9 = DOE
2500 = 25μm


5000 = 50μm


4545 = 0.45+0.45μm


Manufacturer Profile
Shanghai Pullner Filtration Technology Co., LTD.
Established: 2013
Specialty: PP pleated filter cartridges, melt-blown filter cartridges, string wound filter cartridges, stainless steel filter cartridges, and other filtration solutions.
Domestic Offices in China
Beijing, Guangzhou, Fujian, Sichuan, Guangxi, Yunnan, Xinjiang, Inner Mongolia, Shaanxi, Northeast China
Global Branches and Offices
UAE (Dubai), Malaysia (Kuala Lumpur), Russia (Moscow)
60Inch Length PBT Series Polyester Filter Cartridge for 120℃ High Temperature and 4bar Working Pressure
Certifications
60Inch Length PBT Series Polyester Filter Cartridge for 120℃ High Temperature and 4bar Working Pressure

Frequently Asked Questions
What is the brand name of this product?
The brand name is PULLNER.
What is the model number of this product?
The model number is PBT Series.
Where is this product manufactured?
This product is made in China.
