Specifications
Brand Name :
PULLNER
Model Number :
PLZ-PPL
Certification :
ISO19001, ISO14001, ISO45001
Place of Origin :
SHANGHAI,CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
100pcs per day
Delivery Time :
10 working days
Packaging Details :
Carton box after poly bag, 50pcs per carton.
Description
DOE 10-Inch PPL Series Nominal Rating Polypropylene Filter Cartridge

High-performance PP pleated filter cartridge with 68.5mm outer diameter, designed for efficient water and fluid filtration across multiple industries.

Applications
  • Food and Beverage: Beer, wine, juice, soda, oral liquid filtration; additives and oil filtration
  • Water Treatment: Urban water supply, industrial water filtration; power plant condensate filtration
  • Metal Processing: Cutting fluid and coolant filtration; lubricating oil filtration
  • Fine Chemicals: Catalyst filtration; cosmetics raw materials and finished products filtration; chemical auxiliary filtration
  • Petrochemical Industry: Aviation kerosene filtration; diesel and fuel filtration
10Inch Polypropylene Pleated Filter Cartridge for High Flow Water and Beverage Filtration
Technical Specifications
Item Technical Parameters
Filter Medium Polypropylene (PP)
Support/Drainage Polypropylene (PP)
Core/Cage/End Cap Polypropylene (PP)
Outside Diameter 2.7" (68.5mm)
Length 10", 20", 30", 40"
Micron Ratings 0.1um, 0.22um, 0.45um, 1um, 2um, 3um, 5um, 10um, 20um, 30um, 60um
Filtration Area 0.4-0.7m²
Max. Operating Differential Pressure ΔP≤0.35MPa at 25℃
Max. Operating Differential Pressure (Reverse Direction) ΔP≤0.28MPa at 60℃
Sterilization Temperature 30 minute cycles @121℃
Max. Operating Pressure 4bar/21℃, 2.4bar/80℃
Material Construction
Filter Media Polypropylene (PP)
Support/Drainage Polypropylene (PP)
Cage/Core/End Caps Polypropylene (PP)
Seal Material Silicone, NBR, Vit, EPDM
Manufacturer Profile
10Inch Polypropylene Pleated Filter Cartridge for High Flow Water and Beverage Filtration
Shanghai Pullner Filtration Technology Co., LTD.

Established: 2013

Specialization: PP pleated filter cartridges, melt-blown filter cartridges, string wound filter cartridges, stainless steel filter cartridges, and related filtration products

Domestic Offices in China

Beijing, Guangzhou, Fujian, Sichuan, Guangxi, Yunnan, Xinjiang, Inner Mongolia, Shaanxi, Northeast China

Global Branches and Offices

UAE (Dubai), Malaysia (Kuala Lumpur), Russia (Moscow)

Pullner Laboratory
10Inch Polypropylene Pleated Filter Cartridge for High Flow Water and Beverage Filtration
Certification

10Inch Polypropylene Pleated Filter Cartridge for High Flow Water and Beverage Filtration 10Inch Polypropylene Pleated Filter Cartridge for High Flow Water and Beverage Filtration

Frequently Asked Questions
What is the brand name of this product?

The brand name is PULLNER.

What is the model number of this product?

The model number is PLZ.

Where is this product manufactured?

This product is made in China.

What is the main function of this product?

The main function is beverage filtration and industrial fluid purification.

What is the recommended usage time for this product?

The recommended usage time is 6-12 months.
