Specifications
Brand Name :
PULLNER
Model Number :
83 Series
Certification :
ISO14001/ISO19001/ISO54001
Place of Origin :
Shanghai, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
50PCS per month
Delivery Time :
1 Month
Packaging Details :
Individual packaged in carton box after poly bag.
Description
83 Series Pleated Filter Cartridge Diameter 80mm

The 83 Series pleated filter cartridge is specifically engineered for wet process filtration in FPD (flat-panel display) manufacturing applications. Featuring an expanded filtration area and enhanced flow capacity, this cartridge delivers optimal performance for 5-6 generation production lines with flow requirements up to 120L/Min.

Product Specifications
Filter Media
PFL:PTFE(Hydrophobicity) PFLH:PTFE(Hydrophilic)

EPS:PES HPPV:PP
Cage/Core/End Caps
Polypropylene (PP)
Seal Material
EPDM, Silicone, V
Maximum Operating Temperature
80℃
Maximum Operating Difference Pressure
4bar/21℃

2.4bar/80℃
Dissolution Content
Less than 30mg/10"

Less than 0.25EU/ml/10"
Product Series Configuration
Series Micron Rating Length End Cap Type Seal Material
83 PFL: 0.2μm, 0.5μm, 1.0μm, 3.0μm, 5.0μm, 10μm 10" C5=222/Flat
C6=226/Flat		 E=EPDM
S=Silicone
V=V
PFLH: 0.2μm, 0.5μm, 1.0μm, 3.0μm, 5.0μm, 10μm
EPS: 0.05μm, 0.1μm, 0.22μm, 0.45μm, 0.65μm, 1.2μm, 20μm, 40μm, 70μm, 90μm
HPPV: 0.5μm, 1.0μm, 1.5μm, 3.0μm, 5.0μm, 10μm
Manufacturer Profile

Shanghai Pullner Filtration Technology Co., LTD.
Established: 2013
Specialty: PP pleated filter cartridges, melt-blown filter cartridges, string wound filter cartridges, stainless steel filter cartridges, and more.

Domestic Offices in China

Beijing, Guangzhou, Fujian, Sichuan, Guangxi, Yunnan, Xinjiang, Inner Mongolia, Shaanxi, Northeast China

Global Branches

UAE (Dubai), Malaysia (Kuala Lumpur), Russia (Moscow)

83 Series Pleated Filter Cartridge with 80mm Diameter and 120L/Min Flow Capacity for 0.05μm Filtration
Certification
83 Series Pleated Filter Cartridge with 80mm Diameter and 120L/Min Flow Capacity for 0.05μm Filtration
83 Series Pleated Filter Cartridge with 80mm Diameter and 120L/Min Flow Capacity for 0.05μm Filtration
83 Series Pleated Filter Cartridge with 80mm Diameter and 120L/Min Flow Capacity for 0.05μm Filtration
83 Series Pleated Filter Cartridge with 80mm Diameter and 120L/Min Flow Capacity for 0.05μm Filtration
Frequently Asked Questions
What is the brand name of this product?
The brand name is PULLNER.
What is the model number of this product?
The model number is 83 Series.
Where is this product manufactured?
This product is made in China.
