Contamination Free PP FDA 154gpm High Flow Filter Cartridge
Contamination Free PP FDA 154gpm High Flow Filter Cartridge
Contamination Free PP FDA 154gpm High Flow Filter Cartridge
Contamination Free PP FDA 154gpm High Flow Filter Cartridge
Contamination Free PP FDA 154gpm High Flow Filter Cartridge
Contamination Free PP FDA 154gpm High Flow Filter Cartridge
Specifications
Brand Name :
PULLNER
Model Number :
PHBG
Certification :
FDA
Place of Origin :
Shanghai China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability :
1000pcs per week
Delivery Time :
7 days
Packaging Details :
Carton box after poly bag. 4pcs per carton
PHBG :
Bag Filter Replacement High Flow Cartridge Filter
OD :
152mm
Removal rating :
1um, 2um, 5um, 10um, 15um, 20um, 30um, 50um, 70um, 100um
Medium :
PP, PET, Glass Fiber
Length :
20"(508mm), 40"(1016mm), 60"(1524mm)
Filter area :
6.6㎡
Flow rate :
35m³/h
Max. Operating Temperature :
82℃
Filtration Efficiency :
high
Max. Operating Differential Pressure :
3.5bar@21℃
Description

35m³/Hr 5 Micron Size 1 Size 2 Bag Filter Replacement High Flow Cartridge Filter

General information
PLBG series bag filter pleated high flow filter cartridge is designed to replace Size 1 and Size 2 bag filters. PP pleated type provides a cost-effective alternative with higher removal efficiencies over standard bag media configurations. It’s suitable for existing bag filter vessels, no need add any hardware change. Long service life, save filtration cost.

Material Construction

Filter Media Depth Polypropylene (PP)
Support/Drainage Polypropylene (PP)
Cage/Core/End Cap Glass Fiber reinforced Polypropylene (PP)

Performance

Filtration Micron 1μm, 2μm, 5μm, 10μm, 20μm, 40μm, 70μm, 90μm,
Maximum Operating Differential Pressure 3.5bar / 21°C(Inside to Outside)
Recommend Change-out Differential Pressure 1.0 bar / 21°C(Inside to Outside)
Hot Water Sterilization 77-82℃/30min,
Maximum Operating Temperature 82°C

Flow Rate and Filtration Area

Size

Design Flow Rate

(m3/hr)

Max Flow Rate

(m3/hr)

Filtration Area

(m2)
1# 10 25 1.6
2# 20 50 3.4

Ordering Information

PLBG 0100 01 E

Series Micron Length Seal Material
0100 =1.0μm 2000 =20μm 01(1#) =330mm E =EPDM
PLBG 0300 =3.0μm 4000 =40μm 02(2#) =660mm S =Silicone
0500 =5.0μm 7000 =70μm Customization V =Viton
1000 =10μm 9000 =90μm
