1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface
1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface
1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface
1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface
1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface
1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface
1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface
1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface
Specifications
Brand Name :
OEM/Customized
Model Number :
ZH101BH065-01A-TQ1
Certification :
ROHS、ISO9001、CE
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500K pcs/ Month
Delivery Time :
7-15 working days
Packaging Details :
Foam Cotton And Carton Boxes
Size :
10.1 Inch
Resolution :
1920x1080
Brightness :
280 cd/m² （Typ.）
Display type :
IPS,Normally Black
Outline Dimensions :
229.91(W)×135.74(H)×2.8(T) mm
Operating Temperature :
0℃~+50℃
Description

PCAP Touch Display 10.1 Inch TFT LCD Module 1920x1080 with LVDS interface

The ZH101BH065-01A-TQ1 PACP Touch Display is engineered for high-precision touch performance, exceptional clarity, and industrial-grade durability. Designed with PACP (Projected Capacitive) G+G structure, this 10.1-inch display offers smooth multi-touch functionality, outstanding optical clarity, and long-term stability for demanding B2B environments.

With a 1920x1080 Full HD resolution and 280 cd/m² typical brightness, the ZH101BH065-01A-TQ1 ensures crisp, vibrant visuals for both indoor and controlled-lighting environments. Its PACP Touch Display technology delivers accurate and responsive 5-point touch input, making it ideal for interactive kiosks, industrial control systems, and medical devices.

Applications
The ZH101BH065-01A-TQ1 PACP Touch Display is perfectly suited for:

Industrial control panels

Medical imaging and diagnostic equipment

Self-service kiosks and POS terminals

Smart home control interfaces

Transportation and vehicle-mounted systems

​​​​

Key Features of the ZH101BH065-01A-TQ1 PACP Touch Display
Full HD Visual Excellence
10.1-inch display with 1920x1080 resolution for high-definition image clarity and precise detail reproduction.

Durable PACP G+G Structure
Projected capacitive touch with Glass+Glass construction offers enhanced durability, optical transparency, and long-term stability.

Responsive Multi-Touch Performance
Supports 5-point touch with USB interface for fast, accurate touch response in professional applications.

Industrial-Grade Reliability
Surface hardness of 6H for superior scratch resistance and protection in high-traffic environments.

Product Specification

Product Number ZH101BH065-01A-TQ1
Size 10.1 Inch
Resolution 1920x1080
Brightness 280 cd/m² (Typ.)
Interface LVDS, 40pins Connector
Backlight type 36-white LED, 80mA 27.9V
Outline Dimensions 229.91(W)×135.74(H)×2.8(T) mm
Active Area 125.712(W)x223.488(H) mm
Touch panel with touch panel
Structure G+G
Touch IC ILI2511
Surface Hardness 6H
Touch Point 5 Point
Touch Interface USB

Product Drawing

1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface

1920x1080 PCAP Touch Display 10.1 Inch TFT LCD Module With LVDS Interface

Why Choose ZhanHui TFT LCD Screen?

  • Having been dedicated to industrial vehicle-mounted LCD module applications for 10 years
  • A powerful engineering support team offers a one-stop integrated solution
  • Flexible and efficient customization capabilities, with rapid response to demands
  • Strict quality control system (such as through IATF 16949, ISO 9001)
  • Global logistics and localized service support
  • Highly competitive cost-effectiveness

FQA

1. What is the minimum order quantity?
All our models have MOQ requirements, please get in touch with our salesman for detailed information.

2. Can I take one piece for sample to test the quality?

Yes, We recommend checking the sample before order. You could order the sample before your order.

3. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

4.What can you buy from us?
LCD Modules,LCD Display Screen,High Brightness TFT LCD Display,Touch Screen,OLED Display

5. Why should you buy from us not from other suppliers?
One of the things that sets us apart from other TFT LCD & PCAP touch modules manufacturers is the level of customization we offer. There is no limit to what we can create when we take on a custom project!

Call to Action :

  • Upgrade your device visibility with this premium PCAP Touch Display!

  • Request a Quote Today!

  • Download Full Datasheet (Link)

  • Contact Sales for Volume Pricing

  • Order Samples Now!
