1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen
1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen
1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen
1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen
1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen
1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen
1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen
1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen
Specifications
Brand Name :
OEM/Customized
Model Number :
ZH185PIFHD004-01C-TK1
Certification :
ROHS、ISO9001、CE
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500K pcs/ Month
Delivery Time :
7-15 working days
Packaging Details :
Foam Cotton And Carton Boxes
Size :
18.5 Inch
Resolution :
1920x1080
Brightness :
1100 cd/m² （Typ.）
Display type :
IPS, Normally Black
Outline Dimensions :
430.6(W) x254.8(H) x7.0(T) mm
Operating Temperature :
-20℃~+80℃
Description

Touch Display 18.5 Inch 1920x1080 TFT LCD Screen with 1100nits Brightness

The ZH185PIFHD004-01C-TK1 is 18.5-inch touch display designed to deliver exceptional visual performance and seamless touch interaction for industrial, commercial, and embedded applications. Featuring a full HD resolution of 1920x1080 and a brightness of 1100 cd/m², this touch display provides vivid, high-quality visuals, making it perfect for both indoor and outdoor environments. With USB touch interface and optional HDMI board kits, it offers flexibility for various integration needs.

Why Choose the ZH185PIFHD004-01C-TK1 Touch Display?
High Brightness (1100 cd/m²): The touch display is perfect for high-ambient light environments, ensuring clear visibility in both indoor and outdoor settings, such as kiosks, signage, or industrial machines.

Full HD (1920x1080) Resolution: Delivers crisp, sharp visuals for data-heavy applications, improving the user experience and increasing operational efficiency.

Touch Interaction: Equipped with an USB touch interface and driven by the ILI2510 touch driver IC, this touch display ensures smooth and responsive touch input for interactive applications.

Optional HDMI Board: For flexibility in modern multimedia applications, the HDMI board kit offers seamless integration with devices requiring HDMI input.

The ZH185PIFHD004-01C-TK1 touch display is a versatile solution designed for high-performance applications across various industries:

Digital Signage & Interactive Displays

Kiosk Systems & Point of Sale (POS) Solutions

Industrial Control Panels & HMI Systems

Medical and Diagnostic Equipment

Automated Machinery and Equipment Displays

Product Specification

Item Number ZH185PIFHD004-01C-TK1
Screen Size 18.5 Inch
Resolution 1920x1080
Brightness 1100 cd/m²(Typ.)
Display Mode IPS, Normally Black
Interface LVDS, 30pins Connector
Active Aera 408.96(W) x230.04(H) mm
Outline Dimension 446.05(W) x271.18(H) x11.1(T) mm
Backlight input current 480mA 49V
Operating Temperature -20℃~+80℃
Storage Temperature -30℃~+80℃
touch panel with touch panel
touch interface USB
Touch driver IC ILI2510
HDMI Board Optional HDMI Board kits

Product Drawing

1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen

1100nits Brightness PCAP Touch Display 18.5 Inch 1920x1080 TFT LCD Screen

FQA

1. What is the minimum order quantity?
All our models have MOQ requirements, please get in touch with our salesman for detailed information.

2. Can I take one piece for sample to test the quality?

Yes, We recommend checking the sample before order. You could order the sample before your order.

3. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

4.What can you buy from us?
LCD Modules,LCD Display Screen,High Brightness TFT LCD Display,Touch Screen,OLED Display

5. Why should you buy from us not from other suppliers?
One of the things that sets us apart from other TFT LCD & PCAP touch modules manufacturers is the level of customization we offer. There is no limit to what we can create when we take on a custom project!

Ready to integrate the ZH185PIFHD004-01C-TK1 touch display into your business solution?
Contact us today for further information, quotes, or customized options to meet your specific requirements.
