700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel
700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel
700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel
700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel
700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel
700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel
700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel
700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel
Specifications
Brand Name :
OEM/Customized
Model Number :
ZH070HC70061-02
Certification :
ROHS、ISO9001、CE
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500K pcs/ Month
Delivery Time :
7-15 working days
Packaging Details :
Foam Cotton And Carton Boxes
Size :
7.0 Inch
Resolution :
800x480
Brightness :
700 cd/m² （Typ.）
Display type :
TN,Normally White
Outline Dimensions :
164.8(W) x100.0(H) x3.5(T) mm
Operating Temperature :
-20℃~+60℃
Description

700nits 7 Inch TN TFT LCD Display High Brightness LCDLCD 800x480 Optional Touch Panel

Upgrade your devices with the ZH070HC70061-02, a high-performance 7.0-inch High Brightness LCD Display engineered by Shenzhen Zhanhui Photoelectric Technology. Designed for industrial and commercial applications, this color LCD features 800(RGB)×480 resolution for sharp visuals, 700 cd/m² brightness for optimal outdoor visibility, and anti-glare, 3H hardness surface for extra protection.

This 7 Inch High Brightness LCD Display Key Features:

Stunning Visuals – TFT active-matrix color LCD with 262K color depth, delivering vivid, true-to-life images

Operating Temp – Reliable performance in extreme temperatures (-20°C to 60°C), suit for outdoor and harsh environments

Anti-Glare Surface – Enhanced readability even under direct sunlight

Industrial-Grade Durability – Rugged design meets RoHS compliance and endures years of continuous use

High-Brightness – White LED backlighting with 700 cd/m² brightness for clear visibility in all light conditions

Compact and Slim – Outline size of 164.8×100.0×3.5 mm and an active area of 154.08×85.92 mm makes it easy to integrate into any device.

Standard Interface – TTL parallel RGB interface simplifies integration into existing hardware

This 7-inch High Brightness LCD Display is perfect for:
– Industrial control panels
– Medical and diagnostic equipment
– Kiosks and vending machines
– Marine and automotive displays
– Portable devices needing rugged, high-contrast screens

Company's focus on the core

  • Industrial-Grade TFT/OLED Displays (0.96" to 32")
  • Brightness up to 1000cd/m² ~2500cd/m² Sunlight Visibility
  • Wide Temperature -30℃ to +80℃ ,-40℃ to +95℃
  • Touch Solutions: Resistive/Capacitive/Cover Glass
  • TN/IPS Panels | Custom Backlight Systems

Product Specification

item ZH070HC70061-02
Screen Size 7.0 Inch
Resolution 800x480
Brightness 700 cd/m²(Typ.)
Interface FPC 40pins Connector
Display Mode
TN, Normally White
Color 262K
Viewing Direction 6 o'clock
Surface Treatment Anti-Glare,Hardness:3H
Active Aera 154.08(W) x85.92(H) mm
Outline Dimension 164.8(W) x100.0(H) x3.5(T) mm
Backlight 27-Chip white LED, 180mA 10V
Operating Temperature -20℃~+60℃
Storage Temperature -20℃~+65℃
Touch Panel Optional Touch Panel

Product Drawing

700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel

700nits 7 Inch High Brightness TN TFT LCD Display 800x480 Optional Touch Panel

Why Choose ZhanHui TFT LCD Screen?

  • Having been dedicated to industrial vehicle-mounted LCD module applications for 10 years
  • A powerful engineering support team offers a one-stop integrated solution
  • Flexible and efficient customization capabilities, with rapid response to demands
  • Strict quality control system (such as through IATF 16949, ISO 9001)
  • Global logistics and localized service support
  • Highly competitive cost-effectiveness

FQA

1. What is the minimum order quantity?
All our models have MOQ requirements, please get in touch with our salesman for detailed information.

2. Can I take one piece for sample to test the quality?

Yes, We recommend checking the sample before order. You could order the sample before your order.

3. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

4.What can you buy from us?
LCD Modules,LCD Display Screen,High Brightness TFT LCD Display,Touch Screen,OLED Display

5. Why should you buy from us not from other suppliers?
One of the things that sets us apart from other TFT LCD & PCAP touch modules manufacturers is the level of customization we offer. There is no limit to what we can create when we take on a custom project!

Call to Action :

  • Upgrade your device visibility with this premium High Brightness LCD Display !

  • Request a Quote Today!

  • Download Full Datasheet (Link)

  • Contact Sales for Volume Pricing

  • Integrate Brilliance - Order Samples Now!
