Specifications
Price :
2500usd
Packaging Details :
carton
Resolution :
1μΩ
Application :
Winding Resistance Tester
Model Number :
MYRS
Measurement accuracy :
0.5%
Customized support :
OEM
Supply Ability :
1000pcs/month
Operating Temperature :
-10℃~40℃
Place of Origin :
China Mainland
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Time Resolution :
1s
Delivery Time :
1 week
Accuracy Class :
Standard Accuracy
Place of origin :
Hebei, China
Current Resolutio :
1μΩ
Voltage :
220 V
Working power supply :
AC220V ± 10%, 50Hz ± 1Hz
Power :
Electronic
Warranty :
2 Years
MOQ :
1
Weight :
12kg
Brand Name :
MINGYANG
Measurement range :
1-1999μΩ
Measuring Range :
1-1999μΩ
Display mode :
three-and-a-half-digit LCD
Volume :
380*350*260 mm
Type :
Winding Resistance Tester
Description
Handheld 10A Large Screen Touch DC Winding Resistance Ohmmeter for Transformer Test

Basic Info.

Model NO.
MYRS
Max Diameter of Workpiece
<500mm
Mass Scope of Workpiece
<900kg
Type
Strength Testing Machine
Maxcapacity
<1000kN
Accuracy Grade
0.5
Load Way
Electronic Load
Loading Method
Static Load
Control
Manual Control
Weight
0-100kg
Power Source
AC220V
Oil Cylinder Position
Top
Measurement Accuracy
± (0.2%+2)
Work Temperature
-10°C~ 50°C
Power Frequency
50±1Hz
Work Power
110V-400V Adjustable
Transport Package
Wooden Box with Foam Inside
Specification
53.00cm * 42.00cm * 30.00cm
Trademark
MINGYANG
Origin
Hebei, China
HS Code
9030332000
Production Capacity
200
Product Overview

The Hand-held Transformer Winding Resistance Meter is an essential testing instrument designed for transformer manufacturing and power sector applications. This portable resistance tester comes with a comprehensive 2-year warranty.

Transformer DC resistance testing is a critical requirement for semi-finished products, finished product factory testing, installation, overhaul, tap changer modifications, handover testing, and preventive maintenance in the power sector.

Key Applications
  • Checking welding quality of winding joints
  • Detecting short circuits between winding turns
  • Verifying voltage tap changer contact quality
  • Ensuring tap changer position accuracy
  • Identifying broken lead wires and strand breaks
Technical Specifications
Test Current Measuring Range Accuracy
<20mA 100Ω-50KΩ ±(0.5%+2)
±(0.2%+2)
40mA 1Ω-200Ω
200mA 100mΩ-50Ω
1A 10mΩ-10Ω
3A 5mΩ-3Ω
10A 0.5mΩ-0.2Ω
Minimum Resolution: 0.1μΩ
Operation Method: Touch Screen Operation
Host Dimensions: 252*160*65(mm)
Outer Box Dimensions: 425*335*210(mm)
Host Weight: 2KG
Outer Box Weight: 8KG
Battery Specifications: 14.8V 5200mAh
Test Lead Length: Standard 5 meters (customizable)
Product Features
  • Advanced power supply technology for superior performance
  • Compact size and lightweight design for portability
  • High output current capability
  • Excellent repeatability and anti-interference performance
  • Comprehensive protection functions
  • High-speed microcontroller automation
  • Automatic discharge and discharge alarm functions

Product Gallery

Handheld 10A Large Screen Touch DC Winding Resistance Ohmmeter for Transformer TestHandheld 10A Large Screen Touch DC Winding Resistance Ohmmeter for Transformer TestHandheld 10A Large Screen Touch DC Winding Resistance Ohmmeter for Transformer TestHandheld 10A Large Screen Touch DC Winding Resistance Ohmmeter for Transformer Test
