Specifications
Brand Name :
Anycut
Model Number :
ZK1750
Certification :
CE/FCC/RoHS
Place of Origin :
Shenzhen
MOQ :
1 piece
Price :
$742-1330/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1-4 pieces：2days ;5-30 pieces：2-15 days;30-100 pieces:20 days
Delivery Time :
20-30 work days
Packaging Details :
L2110mm*600mm*440mm
Item :
Automatic patrol edge vinyl cutting plotter ZK1750
Max.media width :
1750mm
Max.cutting width :
1600mm
Control panel :
5.0 Inch LCD Touch Screen
Number of heads :
1
Auto contour cut :
High-resolution camera(automatically contour cutting)
Drawing instruction :
Automatic recognition DMPI and HPGL
Connect or interface :
USB cable/Udisk/WIFI(optional)
Support software :
CDR/AI/PS/Contour software/signmaster(optional)
Memory :
1G
Motor :
Micro step subdivision motor
Main board :
ARM smart dual-core chip
Supported materials :
Reflective film, PVC, Vinyl, Cardboard
Blade adjustment type :
Tool-free digital pressure adjustment
Description
ZK1750 Camera Auto Positioning Vinyl Cutter 69inch Cutting Plotter With 2000g Force WIFI Connectivity


The ZK1750 Camera Auto Positioning Cutting Plotter:

✅ Ultra-Precision Camera Alignment

Built-in CCD camera auto-detects printed marks for ±0.01mm cutting accuracy, eliminating manual alignment errors and maximizing material utilization.

✅ 2000g Super Cutting Force

Effortlessly slices through thick roll materials up to 2mm, including reflective film, PVC board, and self-adhesive vinyl, ideal for signage and packaging.

✅ 10m Error-Free Auto-Alignment

Advanced anti-deviation system ensures consistent, distortion-free cutting even on large-format 10m graphics, perfect for vehicle wraps and billboards.

✅ 700mm/s High-Speed Performance

Boosts productivity with fast cutting speeds, handling high-volume orders efficiently without compromising precision.

✅ Wireless & Offline Connectivity

WiFi + USB + U 盘 support allows flexible file transfer, enabling offline operation for greater shop floor mobility.

✅ Durable Industrial Build

Heavy-duty frame and micro-stepping motor ensure long-term stability, reducing maintenance costs and downtime.

Item Automatic patrol edge vinyl cutting plotter ZK1000
MODEL ZK1750
Max. media width 1750mm
Max. cutting width 1600mm
Packing size L 2110mm*W 400mm*H 440mm
Machine size L 2000mm*W 600mm*H 1100mm
Gross/Net weight 55kgs/49kgs
Control panel 5.0inch LCD touch screen
Motor Micro step subdivision motor
Cutting length Unlimited
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.cutting speed 700mm/s
Max.force 2000g
Main board ARM smart dual-core chip
Auto contour cut Camera
Number of heads 1
Blade type Rowland blade
Floorstand yes
Drawing instruction Automatic recognition DMPI and HPGL
Connect or interface USB cable/Udisk/WIFI(optional)
Power ﹤100w
Working environment ﹢5℃﹣﹢35℃
Power supply 100v-240v(adaptive),50HZ/60HZ
Support software CDR/AI/PS/Contour software/signmaster(optional)
Memory 1G
Support system All versions of windows
