Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter
Specifications
Brand Name :
Anycut
Model Number :
ZK760
Certification :
CE/FCC /RoHS
Place of Origin :
Shenzhen
MOQ :
1 Piece
Price :
$328~485/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20-30 work days
Packaging Details :
Outer box:L1100mm*W330mm*H280mm leg frame:L1000mm*W170mm*H550mm
Max.cutting width :
640mm
Auto contour cut :
Camera(automatically contour cutting)
Control panel :
Pure capacitive LCD touch screen
Maximun sutting length :
Unlimited
Cutting speed :
700mm/s
Max. force :
1000g
Connect or interface :
USB cable/Udisk/WIFI(optional)
Memory :
1G
support software :
CDR/AI/PS/Contour software/signmaster(optional)
support system :
All versions of windows
Description

Vacuum Adsorption Automatic Induction Feeding Paper 760mm Stepper Motor Cutting Plotter



The ZK760 is a high-precision, user-friendly cutting plotter designed for sticker, label, and sign-making professionals. It features automatic induction feeding paper with vacuum adsorption, ensuring your material stays flat and stable for clean, accurate cuts every time.

Equipped with a built-in camera for automatic contour cutting, it detects printed registration marks to perfectly cut around pre-printed designs, making it ideal for producing complex stickers, decals, and heat transfers. The machine supports WiFi wireless connection for seamless remote operation, and its pure capacitive LCD touch screen offers intuitive control.

Boasting a maximum cutting width of 640mm and a speed of up to 700mm/s, the ZK760 balances speed and precision (±0.01mm cutting accuracy). It uses durable Rowland blades and delivers a maximum force of 1000g, handling a wide range of materials from vinyl and sticker paper to heat transfer films.



MODEL ZK760
Max. media width 760mm
Max. cutting width 640mm
Auto contour cut Camera (automatically contour cutting)
Control panel Pure capacitive LCD touch screen
Packing size (outer box) L 1100mm*W 330mm*H 280mm
Packing size (leg frame) L 1000mm*W 170mm*H 550mm
Gross/Net weight 29kgs/25kgs
Maximum cutting length Unlimited
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Cutting speed 700mm/s
Blade type Rowland blade
Max.force 1000g
Connect or interface USB cable/Udisk/WIFI(optional)
Power ﹤100w
Working environment ﹢5℃﹣﹢35℃
Power supply 100v-240v(adaptive)
Support software CDR/AI/PS/Contour software/signmaster(optional)
Memory 1G
Support system All versions of windows
