Specifications
Brand Name :
Anycut
Model Number :
ZKSVD370
Certification :
CE/FCC/RoHS
Place of Origin :
shenzhen
MOQ :
1
Price :
$1499~1684/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4pieces/2days;5~30pieces/15days;31~100pieces/20days
Delivery Time :
20~30 work days
Packaging Details :
L890mm*W580mm*H570mm
Max force :
2000g
Suitable cutting material :
Self-adhesive sticker/coated paper/PVC
Connect or interface :
USB cable/Udisk/web cable/WIFI
Blade type :
Rowland blade
Auto contour cut :
Camera（automatically cintour cutting)
Control panel :
4.3 inch touch screen
Support software :
CDR/AI/PS/Contour software/Signmaster
Positioning mode :
Qr code/Dot/Right angle
Support system :
All version of windows
Max cutting width :
340mm
Description

Double-head Cutting Trolley 1600mm/s High Speed Label Cutting Machine With Half-cut And Full-cut Function


  • Dual Knife Head Carriage: Boosts productivity with simultaneous cutting, ideal for high-volume jobs.
  • 1600mm/s High-Speed Servo Motor: Delivers ultra-fast, precise cutting while maintaining stability for full & half-cut tasks.
  • Auto Contour Cutting: Built-in camera automatically identifies QR codes/dots for seamless contour cutting.
  • Flexible Connectivity: Supports USB, U-disk, Ethernet, and WIFI for easy integration into any workflow.
  • Wide Material Compatibility: Cuts self-adhesive sticker, coated paper, PVC, and more up to 450gsm.
  • User-Friendly Operation: 4.3-inch touch screen, Roland blade, and full compatibility with all Windows versions & design software (CDR/AI/PS).
  • Compact & Efficient: 370mm max media width, ±0.01mm cutting accuracy, and <150W low power consumption.


Double-head Cutting Trolley 1600mm/s High Speed Label Cutting Machine With Half-cut And Full-cut Function



Double-head Cutting Trolley 1600mm/s High Speed Label Cutting Machine With Half-cut And Full-cut Function



MODEL ZKSVD370
Max. media width 370mm
Max. cutting width 340mm
Auto contour cut Camera (automatically contour cutting)
Control panel 4.3inch touch screen
Motor High speed servo motor
Positoning mode Qr code/Dot/Right angle
Number of heads 2
Blade type Rowland blade
Packing size L 890mm*W 580mm*H 570mm
Machine size L 768mm*W 455mm*H 336mm
Gross/Net weight 48kgs/42kgs
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.material thickness 450gsm
Max. cutting speed 1600mm/s
Max.force 2000g
Connect or interface USB cable/Udisk/web cable/WIFI
Power ﹤150w
Working environment ﹢5℃-﹢35℃
Power supply 100v-240v(adaptive)
Suitable cutting material Self-adhesive sticker/coated paper/PVC
Support software CDR/AI/PS/Contour software/Signmaster(optional)
Memory 1G
Support system All versions of windows
