Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell
Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell
Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell
Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell
Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell
Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell
Specifications
Brand Name :
Yinlong
Model Number :
40ah
Certification :
UN38.3 , MSDS
Place of Origin :
CHINA
MOQ :
100
Price :
USD29
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
1000000 Pcs / Monthly
Delivery Time :
7 working days
Packaging Details :
Carton + Pallet
Voltage :
2.3V
Capacity :
40Ah
Cycle Life :
30000 cycles
Chemistry :
LTO
Discharge :
10C~20C
Charge :
10C
Self-Discharge Rate :
Less than 2% per month
Warranty :
5 years
Description

Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Battery

Yinlong Lithium Titanate (LTO) batteries are engineered for exceptional performance, safety, and longevity. Based on advanced lithium titanate oxide technology, these batteries offer ultra-fast charging, outstanding low-temperature performance, and an industry-leading lifespan. Designed for high-demand applications such as electric buses, energy storage systems, industrial equipment, and military-grade devices, Yinlong LTO cells provide reliable power under the most challenging conditions.


Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell


Key Features:

  • Ultra-Fast Charging
    Achieves 80% charge in under 10 minutes, dramatically reducing downtime.

  • Exceptional Lifespan
    Over 25,000 charge-discharge cycles with minimal capacity degradation.

  • Wide Operating Temperature Range
    Performs reliably from -40°C to +60°C, ideal for extreme environments.

  • Outstanding Safety
    LTO chemistry is thermally stable and highly resistant to thermal runaway, overcharging, and short circuits.

  • High Power Output
    Capable of high discharge rates for applications requiring instant energy delivery.

  • Low Internal Resistance
    Ensures high efficiency and minimal heat generation, even under heavy load.

Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell


Specification :



Item Specification
1 Chemistry LTO
2 Nominal Capacity 35Ah /40AH /45AH
3 Nominal Voltage 2.3V
4 AC-impedance(1000Hz) 0.2 ~ 0.7mΩ
5 Weight 1.22 ± 0.1KG
6 Dimension (mm) Diameter x Height 66X 160
7 Maximum Charge Current at Room Temperature 10 C (Continuous)
Charging Voltage 2.9V
8 Maximum Discharge Current at Room Temperature10 10C~20C
Discharge End Voltage 1.6V(>0℃),2.0V(≤0℃)
9 Max Operating Temperature Range
Charge 0℃ ~ 65℃
Discharge -35℃ ~ 65℃
*Cells should be stored at 20%SOC-40%SOC or the voltage is between 3.275V and 3.305V.

Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell

Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell


Applications :


  • Public electric transportation (e-buses, trams)

  • Port and airport AGVs

  • Fast-charging EV infrastructure

  • Frequency regulation and energy storage

  • Military communications and mobile base stations

  • Cold climate backup power systems




Yinlong 66160 High Discharge Rate LTO Battery Cell 2.3V 30Ah 35Ah 40Ah 45Ah Lifep4 Battery Cell
