Specifications
Brand Name :
HEROLASER
Model Number :
ML-MF-200l-LC
Certification :
CE/ISO9001/FDA
Place of Origin :
CHINA
MOQ :
1 Set
Price :
$
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram,Paypal
Supply Ability :
100 Sets Per Month
Delivery Time :
7-10 Work days
Packaging Details :
Plywood Box
Model :
ML-MF-200l-LC
Laser Power :
200W
Laser Source Type :
IPG Fiber Laser Source
Laser Wavelength :
1064 nm
Cooling Method :
Water cooling
Water Temperature :
18-22 ℃
Scan Width :
10-60mm
Air Pressure :
0.5-0.8 MPa
Description

Fiber Laser Rust Removal Machine 200W Removal Resin Noncontact Cleaning

laser cleaning machine can remove resin,oil,stain,contaminant,rust,coating,plating,paint etc,.Laser cleaning is a new technology based on the interaction effect between laser and matter.Unlike traditional mechanical cleaning,chemical cleaning and ultrasonic cleaning it does not require any CFC that destroys the ozone layer Organic solvents,no pollution,no noise,harmless to the human body and the environment,it is a "green"cleaning technology.

CE Approve Laser Paint Cleaner

Technical Parameter

Description of high efficiency laser cleaning machine
Model ML-MF-200l-LC
Laser power 200W

Laser source type

 IPG fiber laser source
Laser wavelength 1064 nm
Cooling method Water cooling
Cooling water Deionized water
Water temperature 18-22 ℃

Cabinet size

 1420mm*850mm*1370mm (L*W*H)
Total weight(with water tank) 225kg
Maximum power 2000W
Focal depth 10mm
Scan width 10-60 mm
Auxiliary gas Compressed air/Nitrogen
Air pressure 0.5-0.8 MPa
Optional accessory Handheld / Manipulator
Working condition 5-40 ℃

Applications:

1.Metal surface rust removal

2.Paint cleaning

3.Oil stain, contaminant cleaning

4.Coating surface cleaning

5.Welding/Coating surface pre-treatment.

6.Stone figure surface dust & attachment cleaning.

7.Plastic mold residues cleaning etc...

Features

  • Non-contact cleaning, no damage to work piece
  • Precision positioning, selective cleaning
  • Safe & environment-friendly. Without using chemical detergent or other consumables
  • Easy to operate, with portable mode and could be equipped with robot for automatic cleaning
  • High efficiency, time-saving
  • Stable laser cleaning system, practically maintenance free
Packaging & Shipping

Comparison with traditional cleaning methods:

Comparisons Laser Cleaning Chemical Cleaning Mechanical Grinding Dry ice cleaning
Methods non-contact cleaning contact cleaning Abrasive contact cleaning non-contact cleaning
Harm to base material None Yes Yes None
Efficiency High Low Low Mid.
Consumable Power Chemical Detergent Abrasive paper, grinder, abrasive stone Dry Ice
Washing result Very good, very clear Medium, uneven Medium, uneven Good, uneven
Precision Washing Accuracy controllable. High precision Uncontrollable, low precision. Uncontrollable, medium precision. Uncontrollable, poor precision.
Safety/Environment No pollution Chemical pollution Dust pollution No pollution
Operation Easy to operate, portable or automation optional. Complicated process, higher technical requirement of the operator. Pollution prevention measures required. Need more time & manpower. Pollution prevention measures required. Easy to operate, portable or automatic.
Investment High investment on machine. But no consumable, low maintenance cost Low investment on machine. But expensive consumables Medium investment on machine. High man-power cost. Medium investment on machine. High consumable cost.
