Medium Voltage Step Voltage Regulator
Medium Voltage Step Voltage Regulator
Specifications
Description
Why Automatic Voltage Regulation Matters

As feeder length, load variation and renewable integration increase, voltage drop becomes a common challenge. The VR-32 Medium Voltage Step Voltage Regulator combines an oil-immersed autotransformer with an On-Load Tap Changer (OLTC) to automatically maintain feeder voltage without interrupting power supply, serving 6.6–35 kV distribution systems.

Medium Voltage Step Voltage Regulator

Key Features
  • ±10% regulation range
  • 32 tap positions (≈0.625% per step)
  • 50/60 Hz systems
  • Fully sealed oil-immersed design
  • Automatic controller for voltage monitoring and tap control
  • Suitable for overhead feeders, substations and renewable energy integrationMedium Voltage Step Voltage Regulator
Engineering Advantages

According to the product brochure, the VR-32 provides up to 1,000,000 tap-changing operations, a 20-year design service life, 55°C rated temperature rise and 12% overload capability at a 65°C temperature rise. A single-phase core structure is adopted to reduce no-load losses for continuous outdoor operation.

Medium Voltage Step Voltage Regulator

Typical Applications

Utility distribution feeders, rural overhead lines, renewable energy projects, industrial facilities, mining, data centers and distribution substations.
