250kVA 315kVA 10KV 400V Oil Immersed Transformer Three Phase Copper Winding Dyn11
250kVA 315kVA 10KV 400V Oil Immersed Transformer Three Phase Copper Winding Dyn11
250kVA 315kVA 10KV 400V Oil Immersed Transformer Three Phase Copper Winding Dyn11
250kVA 315kVA 10KV 400V Oil Immersed Transformer Three Phase Copper Winding Dyn11
250kVA 315kVA 10KV 400V Oil Immersed Transformer Three Phase Copper Winding Dyn11
250kVA 315kVA 10KV 400V Oil Immersed Transformer Three Phase Copper Winding Dyn11
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
HENTG Power
Model Number :
S13
MOQ :
2 sets
Price :
CN¥22,079.75-34,188/sets
Certification :
CE
Frequency :
60Hz
Phase :
Three, Single Phase
application :
power transformer
Output Voltage :
415V, 380V, 400V , 110V, 220V, 440V, 480V
Input Voltage :
11kV, 10.5kV, 6.3kV, 6.6kV, 6kV, 10kV, 35kV
Type :
Oil-Immersed Transformer
Color :
Optional
Impedance :
4%
Standard :
IEC / GB
Winding Material :
Copper
Usage :
Power Distribution Transformer
Protection Level :
IP23
Corporation :
KPLC/REA/PEC
Capacity :
200kVA
Coil Structure :
TOROIDAL
Specification :
400kva
Use :
power
Winding :
Cu/copper
Description
Hentg Power Transformer 250kVA 315kVA 10KV 400V Three Phase Oil Immersed Transformer Copper Winding Dyn11

Built with high-quality cold-rolled silicon steel sheets and oxygen-free copper windings, minimizing no-load and load losses.

Lower core and copper losses than IEC standards, reduced temperature rise, and environmentally friendly.

Reduces long-term operational costs while improving system stability and grid efficiency.


Type S13 oil-immersed distribution transformer is based on the original S11 distribution transformer, through the research and application of new materials and new technologies and the combination of independent innovation and technology introduction, through the optimization and innovative design of the core and coil structure, to reduce the no-load loss and noise purposes. Compared with the current national standard JB/T10088-2004, the noise level decreased by 20% on average, and the product performance level reached the domestic advanced level.
Ideal distribution equipment for urban and rural distribution network centers.
250kVA 315kVA 10KV 400V Oil Immersed Transformer Three Phase Copper Winding Dyn11
250kVA 315kVA 10KV 400V Oil Immersed Transformer Three Phase Copper Winding Dyn11

PRODUCT PARAMENTERS
Rated capacity (KVA)
Vector Group
Voltage Combination


No-load loss
Load loss

No-load current
lmpedance


HV
Tapping range
LV

Dy
Yy


30









Yyn0 / Dyn11








10
6.3
6








±5%

±2X2.5%










0.4
80
630
600
1.5
4.0
50




100
910
870
1.3

63




110
1090
1040
1.2

80




130
1310
1250
1.2

100




150
1580
1500
1.1

125




170
1890
1800
1.1

160




200
2310
2200
1.0

200




240
2730
2600
1.0

250




290
3200
3050
0.9

315




340
3830
3650
0.9

400




410
4520
4300
0.8

500




480
5410
5150
0.8

630




570
6200
6200
0.6
4.5
800




700
7500
7500
0.6

1000




830
10300
10300
0.6

1250




970
12000
12000
0.5

1600




1170
14500
14500
0.5

2000




1360
18300
18300
0.4
5.0
2500




1600
21200
21200
0.4


Application Fields
- Municipal Distribution Network
- Industrial Parks
- Wind & Solar Power Systems
- Commercial Buildings & Residential Areas
- Rail Transit & Port Facilities



FAQs
Q: Who are we ?
HENTG POWER is a professional designer, manufacturer and installer of power system solution around the World, was founded in 2011, occupies 100,000 square meter. specializing in reliable, high-performance solutions for global power systems
Q: How can we guarantee quality ?
Always a pre-production sample before mass production; Always final Inspection before shipment, We will provide QC & test reports. We accept FAT(Factory Acceptance Test). Factory can manufacture oil type and dry type distribution transformer, max 500KV 480MVA power transformer, GIS, switchgear, substation, based on ANSI/IEEE/DOE2016/CSA/IEC60076 standard. We will provide you with the guarantee service of over 2 years.
Q: Why choose us?
We have the professional and independent drawing team and technical team, It is expected that we can confirm all the contents on the drawings with you within 7 days. we have a professional technical team with 30+ senior engineers offer 24 hours online service and response within 30 min.
Q: What services can we provide ?
Accept OEM, business payment are negotiated.
