Specifications
Place of Origin :
Jiangsu, China
Brand Name :
HENTG Power
Model Number :
ZGS
MOQ :
2 sets
Price :
CN¥378680/units
Certification :
CE
Type :
distribution transformer
Material :
Copper, 100% Copper Wire
Frequency :
50Hz, 60Hz
Shape :
Rectangle
Winding Material :
Copper
application :
Power
Phase :
Three
Coil Structure :
Wound Coil
Coil Number :
Multi-winding coil
Input Voltage :
3kV, 6kV, 10kV
Output Voltage :
220V, 380V, 440V, 480V, 415V, 400V
Product name :
Oil Immersed Transformer
Rated capacity :
75KVA-3750KVA
Cooling Method :
ONAN ONAF OFAF
Core material :
100% Cooper
Color :
Green
Warranty :
3 Years
Feature :
High Efficiency
Application :
Electronic Equipment
Usage :
High-frequency Tranformer
Description
Custom 3 Phase Pad Mounted Transformer 2500kva Industrial Electricity Transformer 33kv Step-down Transformer
Custom 3 Phase Pad Mounted Transformer 2500kva Industrial 33kv Step Down Transformer
PRODUCT PARAMENTERS
Custom 3 Phase Pad Mounted Transformer 2500kva Industrial 33kv Step Down Transformer
THREE PHASE PAD MOUNTED TRANSFORMER







Capacity (KVA)
HV
Tapping range
LV
No-load loss
Load loss
lmpedance
Efficiency
75


2400
4160
7200
7620
12000
12470
13200
13800
14400
19920
24940
34500




±2X2.5%


110
120
208
240
277
347
415
416
480
600
690
130
100
4.0-6.3
99.03
152



200
1800

99.16
225



350
3100

99.23
300



430
3700

99.27
500



600
5410

99.35
750



880
7500

99.4
1000



1000
10300

99.43
1500



1400
14500

99.48
2000



1800
18300

99.51
2500



2300
23100

99.53
3150







3750







Custom 3 Phase Pad Mounted Transformer 2500kva Industrial 33kv Step Down Transformer


Product Overview

The 2500kVA Three-Phase Pad-Mounted Transformer is a high-capacity distribution solution engineered for outdoor, ground-level applications. Designed to meet the rigorous demands of industrial, utility, and commercial sectors, this transformer offers compact design, secure enclosures, and consistent performance. Built for reliability and safety, it seamlessly integrates into modern power systems while reducing long-term operational costs.

F – Features

  • Three-phase pad-mounted design

  • Oil-immersed self-cooled (ONAN) system

  • Tamper-proof steel enclosure

  • Weather-resistant and corrosion-protected casing

  • Fully sealed tank design

  • Industry-standard compliance (IEEE/ANSI/IEC)

B – Benefits

  • ✅ Outdoor Durability: Built to perform in harsh outdoor conditions without risk of weather-related damage.

  • ✅ Secure Installation: Lockable, tamper-resistant cabinet protects vital components in public or unmonitored spaces.

  • ✅ Compact & Efficient Footprint: Ground-level pad-mounted layout eliminates the need for transformer rooms or overhead equipment.

  • ✅ Low Maintenance Operation: Hermetically sealed system reduces oil degradation and inspection frequency.

  • ✅ Consistent Voltage Output: Delivers stable, efficient power with reduced energy losses, even at full load.

A – Advantages

  • ⚡ High Load Capacity: Easily supports large-scale commercial, utility, or industrial operations with reliable performance.
