Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
HENTG Power
Model Number :
S11
MOQ :
2 sets
Price :
CN¥24,928.75/sets 2-999 sets
Certification :
CE
Frequency :
60Hz
Phase :
Single Phase
application :
power transformer
Output Voltage :
110V, 220V, 380V, 400V , 440V, 480V
Input Voltage :
11kV, 10.5kV, 3kV, 6.6kV, 6.3kV, 35kV, 12.47kV, 6kV
Product name :
3 phase pad mounted transformer
Type :
Pad Mounted Transformer
Standard :
DOE/IEC60076/IEEE
Warranty :
2 Years
Vector Group :
Dyn11/Yyn0/Yd11/YNd11
Usage :
Outdoor Power Line Operation
High Voltage :
11kv 10kv 6.3kv 6kv 14.4KV 25KV 34.5KV
Low Voltage :
120-240/240-480/347/600
Transformer Feed Type :
Radial Feed
Ul Certificate Numbers :
UL-US-2431836-0, UL-CA-2423202-0
Rated Capacity :
75KVA to 10000KVA Available
Secondary Voltage :
480Y/277
Feed Type :
Loop Feed
Cooling Method :
ONAN
Tank Material :
304 Stainless Steel
Dimensions :
71-W x 73-D x 71-H
Insulation Class :
Class A
Description
Step Up Step Down Transformer 225kVA 300KVA 500kVA 750KVA 1000kVA 1500KVA Three Phase Pad Mounted Transformer
PRODUCT PARAMENTERS
Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA
THREE PHASE PAD MOUNTED TRANSFORMER







Capacity (KVA)
HV
Tapping range
LV
No-load loss
Load loss
lmpedance
Efficiency
75


2400
4160
7200
7620
12000
12470
13200
13800
14400
19920
24940
34500




±2X2.5%


110
120
208
240
277
347
415
416
480
600
690
130
100
4.0-6.3
99.03
152



200
1800

99.16
225



350
3100

99.23
300



430
3700

99.27
500



600
5410

99.35
750



880
7500

99.4
1000



1000
10300

99.43
1500



1400
14500

99.48
2000



1800
18300

99.51
2500



2300
23100

99.53
3150







3750







Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA

Feature:​
This 225kVA three-phase pad-mounted transformer adopts a modular plate heat dissipation structure, with a compact layout and high heat dissipation efficiency, suitable for industrial, commercial, and new energy distribution scenarios with limited space. The rated frequency is 50Hz/60Hz, and the maximum operating voltage can reach 38.5kV. The capacity range covers 150kVA to 2500kVA (customizable), meeting the power demand of different scales. It complies with international standards such as ANSI C57 and IEC 60076, as well as domestic standards such as GB 1094 and GB 17467 - 2010, with strict product quality assurance. In the field of industrial power distribution, it can be used in factories, mining equipment, port machinery, etc. In terms of commercial buildings, it is suitable for shopping malls, office buildings, hospitals (substations with limited space), etc. It can also play a role in renewable energy systems, such as PV power station compact substations, energy storage systems, etc. It can also be used for temporary power supply scenarios such as construction sites and exhibition centers.​
Advantage:​
The modular plate heat dissipation structure improves the heat dissipation efficiency and effectively saves space at the same time, enabling easy installation and use in places with limited space. The wide voltage and capacity range and customization services enable it to flexibly adapt to different scales and types of power projects, from the power upgrade of small commercial stores to the power expansion of large industrial enterprises. Strict compliance with international and domestic standards proves the high quality and reliability of the product, allowing users to use it with confidence. Its wide adaptability to application scenarios makes it an ideal choice for various industries to solve power distribution problems. Whether it is a long-term stable power supply scenario or a temporary emergency power supply demand, it can handle it perfectly.​
Benefit:​
For users, the efficient heat dissipation structure ensures the stability of the transformer during long-term operation, reduces the risk of equipment failure caused by overheating, and reduces equipment maintenance costs. The flexible voltage and capacity customization service ensures that users can obtain the most suitable transformer for their needs, avoiding waste of resources and economic losses caused by equipment mismatch. The high-quality product that meets the standards provides users with reliable power guarantee, reduces the interference caused by power problems to production and life, and improves work and life efficiency. The wide adaptability to application scenarios allows users to use this transformer conveniently in different projects and scenarios without spending a lot of time and energy looking for suitable power equipment.
Q: Who are we ?
HENTG POWER is a professional designer, manufacturer and installer of power system solution around the World, was
founded in 2011, occupies 100,000 square meter. specializing in reliable, high-performance solutions for global power systems
Q:How can we guarantee quality ?
Always a pre-production sample before mass production; Always final Inspection before shipment, We
will provide QC & test reports. We accept FAT(Factory Acceptance Test). Factory can manufacture oil type and dry type
distributiontransformer, max 500KV 480MVA power transformer, GIS, switchgear, substation, based on ANSI/IEEE/DOE2016/CSA/IEC60076 standard. We will provide you with the guarantee service of over 2 years.
Q: Why choose us?
We have the professional and independent drawing team and technical team, It is expected that we can confirm all the contents on the drawings with you within 7 days. we have a professional technical team with 30+ senior engineers offer 24 hours online service and response within 30 min.
Q: What servicescan we provide ?
Accept OEM, business payment are negotiated.
