Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
Specifications
Place of Origin :
Hunan, China
Brand Name :
HENTG Power
Model Number :
ZGS
Certification :
CE
Price :
CN¥129369/pieces
Type :
distribution transformer, power transformer, Oil-filled Transformer
Frequency :
50Hz, 60Hz
Winding Material :
Aluminum
Phase :
Three
Coil Structure :
TOROIDAL
Coil Number :
Multi-winding coil
Input Voltage :
3kV, 6kV, 10kV, 15kV, 35kV, 69kV, 110kV, 220kV, 400kV, 115kV, 132kV
Output Voltage :
5V, 400V , 208V, 200V, 415V, 127V, 11kV, 12V , 24V, 48V, 110V, 220V, 36V, 380V, 440V, 480V, 9V
Product name :
Toroidal Transformer
Material :
Aluminum Winding
Application :
Power Distribution System
Usage :
Power Electronic
Transformer type :
Toriodal Transformer
Cooling Method :
ONAN ONAF OFAF
Name :
High Fequency Transformer
Feature :
High Efficiency
MOQ :
2 sets
Description
ONAN Electrical Power Transformer Factory Price 300KVA Three Phase Pad Mounted Transformer
PRODUCT PARAMENTERS
Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer
THREE PHASE PAD MOUNTED TRANSFORMER







Capacity (KVA)
HV
Tapping range
LV
No-load loss
Load loss
lmpedance
Efficiency
75


2400
4160
7200
7620
12000
12470
13200
13800
14400
19920
24940
34500




±2X2.5%


110
120
208
240
277
347
415
416
480
600
690
130
100
4.0-6.3
99.03
152



200
1800

99.16
225



350
3100

99.23
300



430
3700

99.27
500



600
5410

99.35
750



880
7500

99.4
1000



1000
10300

99.43
1500



1400
14500

99.48
2000



1800
18300

99.51
2500



2300
23100

99.53
3150







3750







Aluminum Winding Electrical Power Transformer 300KVA 3 Phase Pad Mounted Transformer.

Product Overview

The 2500kVA Three-Phase Pad-Mounted Transformer is engineered for high-demand power distribution in outdoor and public-access settings. Its sealed and tamper-resistant design ensures maximum safety, while advanced insulation and low-loss core technology provide efficient and reliable operation. Ideal for commercial, industrial, and utility-scale applications, this transformer combines performance, durability, and convenience in one integrated solution.

F – Features

  • Rated Power: 2500kVA

  • Configuration: Three-Phase, Pad-Mounted

  • Type: Oil-immersed, sealed tank construction

  • Cooling Method: ONAN (Oil Natural Air Natural)

  • Weatherproof, corrosion-resistant enclosure

  • ANSI/IEEE/IEC compliant design

  • Low noise emission levels suitable for residential zones

  • Dead-front/tamper-proof design for public safety

  • High-grade silicon steel core with low no-load loss

B – Benefits
