11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz
11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz
11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz
11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz
11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz
11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz
11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz
11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz
Specifications
Brand Name :
HENTG Power
Certification :
CE
Place of Origin :
China
MOQ :
1
Delivery Time :
10
Connection Method :
Dyn11/Yyn0
Temperature Rise :
≤65℃
Rated Capacity :
11000KVA
Input Voltage :
Other
Poles :
3
Usage :
Power,Distribution
Capacity :
Max 1600KVA
Feature :
Longlife
Frequency :
50Hz/60Hz
Shape :
Rectangle
Connection Symbol :
Dyn11,Yyn0 or others
Phase :
Single/Three
Insulation Class :
Class A
Product Type :
Multiple Winding Transformer
Coil :
Copper/Aluminum Coil
Description

Product characteristics

Vacuum circuit breaker or load switch + fuse (combined electrical appliancetechnical solution can be used on the high voltage side of Huashi box. The electricalcharacteristics of the combined electrical structure is that when any phase fuse isblown, the load switch will be guaranteed to trip and cut off the power supply, and themain switch can be closed after replacing the fuse.
The vacuum circuit breaker or load switch + fuse (combination electrical appliance)used in the high voltage side is set up mechanical interlock to prevent misoperation,and the vacuum circuit breaker or load switch + fuse (combination electricalappliance) is set up signal transmission signal to facilitate the background real-timemonitoring of its operating status and remote control function.
11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz
Product Parameters
ltem
Parameter
No
Item
Parameter
Basic Technical Parameters

2
Insulation & Thermal Classes

Type & Model
S11-5000-33/0.69

Insulation Level
Class A
Rated Capacity
5000kVA
a
High-Voltage Side

Rated Voltage(HV / LV)
33kv/0.69kv

Lightning Impulse Withstand(peak)
200kv
Rated Current(HV / LV)
87.5A /4183.7 A

Short-Duration Power-Frequency Withstand(r.m.s.)
85kv
Voltage Ratio
±2 × 2.5 %

Lightning Impulse Withstand (peak)

Short-Circuit Impedance
7%

Short-Duration Power-Frequency Withstand (r.m.s.)
5kv
Vector Group
Dyn11



Rated Frequency
50Hz



Cooling Method
ONAN



Losses, Noise & No-Load Current

4
Other Technical Requirements

No-Load Loss
≤ 3970W (+15%)
4
Overall Dimensions (L × W × H)
2650 mm × 2900 mm × 2750 mm
Load Loss
≤ 39018W (+15%)
b.
Estimated Total Mass
10.7t
Sound Pressure Level
≤ 77 dB(A)



No-Load Current
0.50%



11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz

11000KVA Prefabricated Substation for Solar Wind Power 50Hz/60Hz

Feature
Advantage
Benefit
Integrated Design
Combines inverter,transformer,and HV distribution
Fewer devices, savesspace and installationtime
Modular Structure
Standardized componentsfor quick deliveryand easy O&M
Lower O&M costs,higher reliability
High-efficiency Inverter
>98.5% conversionefficiency
Minimizes power loss,improves energyconversion efficiency
Smart Monitoring
System
Real-time monitoring& remote control
Efficient management and fault alerts
Comprehensive
Protection
Over-voltageover-current short-circuit protection
Ensures safe operation for both equipment and personnel
All-weather Adaptability
IP54 rating,works in harsh environments
Applicable in deserts,plateaus and more


Say goodbye to the long construction cycles and uncertain risks of traditional power generation. We offer prefabricated, modularly designed, and one-stop delivery solutions for prefabricated substations, shortening project construction time by 60% and ensuring faster, more stable, and smarter power supply.



From design to factory commissioning and delivery, the entire substation can be completed in just 4-6 weeks.
Onsite, only foundation leveling, hoisting, and cable connection are required, and power supply is available within a week.

Winning prime time for grid connection of new energy power plants, enterprise expansion, and emergency power supply.



Full-condition simulation pre-commissioning: Over 100 tests, including protection transmission and communication point-to-point testing, are completed in-plant to ensure error-free commissioning.

Military-grade protective enclosure: High-strength steel structure, C5-level corrosion protection (hot-dip galvanizing), IP54 protection rating, and resistance to salt spray, wind, sand, and condensation.

Intelligent internal environment: Industrial air conditioning, fans, electric heaters, and gas fire protection systems work together to maintain a constant temperature and humidity inside the system.
