Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Specifications
Brand Name :
Henrriet
Plate thickness :
42mm x 2 pcs
Pressure method :
Press up and down
Maximum pressure :
1000 T
Heating method :
Thermal oil heat transfer
Packaging Details :
Film with Foam
Price :
Online/offline communication
Opening spacing :
0-200mm
Place of Origin :
China
Maximum temperature :
180℃
Outline dimensions of hot press :
3700mm * 2100mm
Number of layers :
1-layer
Heating cycle motor :
3KW high-temperature pump
Oil cylinder specification :
10pcs*220mmX200mm plunger cylinders+2 lifting cylinders
Delivery Time :
15-20Work days
Hot press plate size :
3700mm x 1300mm
Motor power of hydraulic system :
11KW
Certification :
CE、ISO 9001
Payment Terms :
T/T
Conveyor reducer :
0.75KW
MOQ :
1
Description
Customized 1000T Pressure Automatic Cold and Hot Conveying Press Production Line for Hall Doors, Wood & Plastic Doors
Product Overview

This integrated thermal processing ecosystem merges heavy-duty hot pressing, precision cold forming, and automated material handling into a unified production framework. Its design eliminates manual interventions, enabling a continuous thermal cycling workflow from raw material input to finished product output.

Key Features
Superior Production Capacity

The system's breakthrough lies in its synchronized dual-phase thermal processing. Panels undergo high-temperature curing in the hot press, followed by automatic transfer to the cold press for rapid stabilization. This parallel processing replaces traditional sequential workflows, allowing simultaneous hot pressing and cold forming across dedicated stations.

Integrated Safety and Protection

Engineered for continuous operation in demanding environments, the system incorporates tiered safety mechanisms including mechanical redundancy, thermal safeguards, electrical resilience, and motion control systems to ensure equipment and operator safety.

Wide-Ranging Application Versatility

The system supports diverse door manufacturing categories including Iron-Wood Doors, Aluminum Honeycomb Doors, Wood-Plastic Doors, Mechanism Panel Doors, and Grand Hall Doors for various commercial and residential applications.

Easy Maintenance and Technical Support

Sustained operational excellence requires systematic maintenance protocols including surface hygiene, thermal system calibration, electrical integrity checks, and conveyor health maintenance to ensure sustained performance integrity.

Technical Specifications
Pressure Method Press Up and Down
Maximum Pressure 1000 T
Hot Press Plate Size 3700mm x 1300mm
Plate Thickness 42mm x 2 pcs
Number of Layers 1-layer
Opening Spacing 0-200mm
Motor Power of Hydraulic System 11KW
Heating Cycle Motor 3KW High-temperature Pump
Conveyor Reducer 0.75KW
Oil Cylinder Specification 10pcs*220mmX200mm plunger cylinders + 2 lifting cylinders
Heating Method Thermal Oil Heat Transfer
Maximum Temperature 180℃
Outline Dimensions of Hot Press 3700mm * 2100mm
Company Advantages
  • Two In-House Factories: Better prices and faster delivery with no middlemen markups
  • 30+ Senior Engineers: Custom-built solutions designed around your production needs
  • CE & ISO 9001 Certified: Global-ready equipment meeting international standards
  • 50+ Countries, 1000+ Projects: Proven experience in design and manufacturing worldwide
Service Support
  • Warranty: 1 year
  • Packaging: Film with foam
  • 24-hour customer service hotline with 48-hour response to repair needs
  • Free video training for operators and process guidance manuals
  • Lifetime technical support and software upgrade services
Scope of Application
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Product Display
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Production Workshop
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Product Details
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Corporate Advantages
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Visitors and Communication
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Production Level and Manufacturing Process
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Exhibition and Exchange
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Packaging and Logistics
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
Certificates and Honors
Customized 1000T Pressure Automatic Conveying Press Production Line with Thermal Oil Heat Transfer for Hall Doors and Wood Plastic Doors
