Specifications
Brand Name :
Henrriet
Model Number :
HLY-50T
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Online/offline communication
Payment Terms :
T/T,MoneyGram
Delivery Time :
10-15Work days
Packaging Details :
Film with Foam
Name :
Industrial Hydraulic Press Machine
Max pressuer :
50T
Work platen size :
8000*2000mm
Oil cylinder specification :
100mm * 8pcs
Motor power :
5.5kw
Workd effctively :
1000mm /1300mm / 1500mm / Customizable
Overall dimensions （Standard Model） :
8600*3000*3250mm
Weight (Standard model-about) :
10000kg
Description

Hydraulic Cold Press Machine for Furniture Industry Rock Wool Sandwich Board Stainless Honeycomb Panel Fireproof Door

Product Description:

The eight-cylinder hydraulic cold press is an industrial-grade machine engineered to deliver high-precision pressure through an advanced hydraulic system and multi-cylinder synchronization. It is ideally suited for furniture manufacturing, wooden door production, sheet metal pressing, metal forming, and a variety of industrial laminating applications. Key benefits include exceptional pressure stability, operational simplicity, high throughput, and compatibility with workpieces of diverse dimensions and materials.

Machine Function & Performance Advantages – Engineered for Excellence

The press platens are precision-machined and mirror-polished to eliminate surface imperfections, ensuring clean, consistent contact with sensitive materials. Whether bonding thin veneers or composite laminates, this ultra-smooth platen surface prevents marring and guarantees a premium finish on every panel.

Unrivaled Pressure Uniformity Through Advanced Hydraulics

At the heart of the machine lies an eight-cylinder hydraulic system driven by synchronized oil transmission. Unlike conventional presses that suffer from pressure imbalance, this design delivers perfectly even force distribution across the entire pressing area. It ensures uniform adhesive curing and eliminates weak bonds—critical for high-strength, warp-free lamination.

Speed Meets Smart Control

Fast-acting hydraulic actuators enable rapid platen movement during loading and pressing phases, slashing cycle times without sacrificing stability. Paired with a programmable timer, operators can fine-tune dwell duration for different adhesives and material types—making the machine adaptable to everything from quick-setting PVA to slow-cure polyurethane resins.

Safety Built into the System

Safety isn’t an add-on—it’s engineered in. An intelligent overpressure detection circuit automatically cuts off hydraulic flow when limits are exceeded, protecting both motor and pump from overload damage. The integrated oil bypass valve prevents pressure spikes, while the electrical control system features overload relays, phase-loss protection, and short-circuit safeguards. A prominently placed emergency stop button on the operator panel allows instant shutdown in any situation, meeting global industrial safety standards.

Versatility Across Materials and Production Modes

Maintenance Made Simple, Downtime Kept Minimal

The hydraulic unit is fully enclosed and sealed against contamination, minimizing leaks and extending service intervals. Under normal operating conditions, hydraulic oil only needs replacement once per year.

Machine parameters

Maximum Pressure 50 T (customizable)
Worktable Sizes 8000mm*2000mm (customizable)
Maximum Processing Thickness 1000mm, 1300mm, 1500mm
Power supply 380V/50Hz, three-phase
Power 5.5kW (customizable)
Dwell time 0-99.99 hours (Adjustable)
Platen lift speed 10-12mm/s
Pressure accuracy ±1% (ISO-compliant)
Size 8500mm × 2500mm × 2550mm
Weight 10000KG

Service Support

Warranty: 1 year

Packaging: Film with foam

24-hour customer service hotline, respond to repair needs within 48 hours.

Free video training for operators and provision of process guidance manuals.

Lifetime technical support and software upgrade services.
