Product description:

A Counterweight oil cylinder, also known as a hydraulic counterbalance cylinder or balance oil cylinder, is a critical hydraulic component used in cranes, excavators, concrete pump trucks, aerial platforms, and other heavy-duty machinery. Its primary function is to balance and stabilize the counterweight mechanism, ensuring smooth, controlled, and safe operation during lifting, swinging, or telescopic movements.

By providing hydraulic force to support or counteract heavy loads, the counterweight cylinder enhances machine stability, prevents tipping, and optimizes weight distribution. It plays an essential role in maintaining safety and efficiency in construction, mining, and industrial operations.

hydraulic cylinders are actuators that convert hydraulic energy into linear mechanical force. They have a compact structure, high output force, and smooth operation. They are the core components for performing actions such as pushing, pulling, lifting, and pressing in various mechanical and industrial systems, and are widely used in construction machinery, metallurgy, mining, shipping, and other fields.

Parameters:

Pictures:

Working Principle and Structure

The hydraulic counterweight cylinder operates on the principle of hydraulic pressure and piston movement. When hydraulic oil is supplied to one side of the piston, it pushes the rod outward or inward, adjusting the position of the counterweight or balancing system.

This adjustment allows the equipment to compensate for load variations during operation, maintaining equilibrium and reducing vibration or structural stress.

A typical counterweight oil cylinder includes:

• Cylinder barrel: Made from seamless high-strength steel for durability under pressure.
• Piston and piston rod: Transfers hydraulic energy to mechanical motion.
• Sealing system: Ensures zero leakage and consistent hydraulic pressure.
• Mounting components: Allow secure installation on the counterweight arm or structure.
• Depending on the application, the cylinder can be single-acting (gravity return) or double-acting (powered in both directions), providing flexibility and precision control.

Materials and Manufacturing Process

The cylinder body is made from alloy or carbon steel precision tubes, honed and polished internally to achieve excellent surface smoothness and sealing performance. The piston rod is treated with hard chrome plating or QPQ nitriding for superior corrosion resistance and wear protection.

All parts are CNC machined with tight tolerances to ensure smooth assembly and consistent performance. The welding process utilizes robotic automation for high strength and stability.

High-quality sealing components from global brands such as Parker, Hallite, and NOK are used to provide leak-free operation and extended service life. Every cylinder is rigorously tested according to ISO 9001, DIN, and CE standards to guarantee safety and reliability.

Key Features and Advantages

• High Stability and Safety: Maintains machine balance during lifting or rotating movements.
• Strong Load Capacity: Designed for heavy-duty counterweight systems under high pressure.
• Smooth and Precise Operation: Ensures accurate positioning and stable control.
• Superior Sealing System: Prevents internal leakage and maintains consistent hydraulic performance.
• Corrosion and Impact Resistance: Surface-treated rods withstand harsh environments.
• Customizable Design: Available in different bore sizes, stroke lengths, and mounting configurations.
• Low Maintenance: Simple structure allows easy inspection and replacement of seals.
• Long Service Life: Manufactured with premium materials for reliable, long-term use.

Working principle of hydraulic cylinder:

Applications:

The hydraulic cylinder is an energy conversion device that converts hydraulic energy into mechanical energy. It is the core executive component in the hydraulic system. The hydraulic cylinder uses hydraulic oil to drive the piston to move, converting hydraulic energy into linear reciprocating motion. When the hydraulic oil enters the cylinder barrel, it pushes the piston rod to extend or retract, completing the predetermined action. The direction and speed of its movement are regulated by the hydraulic control system. The hydraulic cylinder consists of a cylinder barrel, cylinder cover, piston and piston rod, sealing device, and buffering device. According to its structure, it can be classified as piston type, plunger type, multi-stage telescopic sleeve type, and gear rack type. Hydraulic cylinders are widely used in machine tools, construction machinery, vehicles, and other fields, featuring a simple structure and smooth movement.

The Counterweight Hydraulic Cylinder is widely used across multiple industries, including:

• Truck Cranes: Adjusts and stabilizes the counterweight during lifting operations.
• Concrete Pump Trucks: Balances the rear counterweight structure for stability during pumping.
• Excavators and Mining Equipment: Controls counterweight positioning during digging or swinging.
• Tower Cranes and Mobile Cranes: Maintains structural balance for safe operation.
• Aerial Work Platforms: Provides hydraulic support for extending or retracting counterweight mechanisms.
• Material Handling Systems: Balances heavy loads in hydraulic arms and lifting platforms.
• Marine and Offshore Equipment: Stabilizes ship-mounted cranes and loading systems.
• Its versatility makes it a crucial component for any machinery that relies on precise hydraulic balance and stability.

Quality Control and Testing

Every cylinder undergoes strict inspection and hydraulic testing before delivery. Quality assurance includes:

Pressure and leakage testing under rated loads

Dimensional accuracy verification

Coating adhesion and corrosion resistance testing

Fatigue and endurance testing for long-term reliability

All products comply with ISO, DIN, and CE standards, guaranteeing consistent performance and safety in demanding industrial environments.
