F3000 Heavy Duty Dump Truck Howo 8x4 Dump Truck 50 Tons
F3000 Heavy Duty Dump Truck Howo 8x4 Dump Truck 50 Tons
F3000 Heavy Duty Dump Truck Howo 8x4 Dump Truck 50 Tons
F3000 Heavy Duty Dump Truck Howo 8x4 Dump Truck 50 Tons
F3000 Heavy Duty Dump Truck Howo 8x4 Dump Truck 50 Tons
F3000 Heavy Duty Dump Truck Howo 8x4 Dump Truck 50 Tons
Specifications
Brand Name :
SHACMAN
Model Number :
SX3315DR366
Certification :
CCC,ISO
Place of Origin :
China
MOQ :
1unit
Price :
USD43,500.00-USD46,000.00 per unit
Payment Terms :
30%TT as deposit, the balance should be paid before delivery; 100% irrevocable confirmed L/C at sight
Supply Ability :
3000units/month
Delivery Time :
30-45 days
Packaging Details :
Nude packing after painted wax
Loading capacity :
40-50 tons
Drive wheel :
8x4
Engine capacity :
> 8L
Fuel type :
Diesel
Gross vehicle weight :
31000
Cab :
with Air conditioner
Description

SHACMAN F3000 8x4 40-50 Ton Construction Work Heavy Duty Dumper Truck

Dump truck is widely used in transporting the construction material, such as sand, stone, gravel, coal, earthwork etc.Main configuration: hydraulic system, which brand HYVA or Chinese top brandMain material: carbon steel, high-strengthen steel T700/T750 Lifting system: middle lifting, front lifting Hydraulic system: HYVA, PERMCO

SHACMAN F3000 Dump Trucks can easily cope with long-distance heavy haul transportation such as mines

and muck in various markets of the world.

Model Shacman F3000 Dump Truck
Driving type 8x4
Weight Complete kerb mass (kg) 12160
GVW (kg) 32500
Dimensions LxWxH (mm) 12000x2490x3450
Body size(mm) 7400x2300x1100,1300,1500
Front/rear overhang(chassis) 1525/1450
Wheel base (mm) 1800+3800+1350
Track width (mm) 2036/1850
Engine Brand Weichai
Model WP10.336
Power (kw/HP) 247/336
Max. torque (N.m)/rpm 1250/1200-1600
Displacement (L) 9.726
Emission standard Euro 2
Axles Brand HANDE
Front axle 7500kg
Rear axle 16000kg,Double reduction driving axle with inter-wheel differential and differential lock
Ratio 5.262
Optional 9500kgfront axle
Performance Max. speed ( km/h) 76
Min. turning circle (m) 15
Min. ground clearance (mm) 314
Approach/Departure angle(°) 28/30
Max. Gradeability (%) 32
Transmission Brand FAST
Model 9JS135
Control type Manual
Gear shift 9-forward and 1-reverse speeds

F3000 Heavy Duty Dump Truck Howo 8x4 Dump Truck 50 Tons

F3000 Heavy Duty Dump Truck Howo 8x4 Dump Truck 50 Tons

Packing & Delivery

Packing:Nude packing after painting wax or according to your requirement.
Shipping:By bulk cargo carrier, RORO.

F3000 Heavy Duty Dump Truck Howo 8x4 Dump Truck 50 Tons
