Specifications
Brand Name :
LINKONG
Model Number :
LTB-1204
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Supply Ability :
1-300
Delivery Time :
5
Description

Main Features

1.Adopting Quan chai famous diesel engine,good reliability,large torque reserve,low fuel consumption, high economic benefits;

2.Operate independently double clutch ,high transfer ability,reliable effect,operation more comfortable;

3.Gear box ,12 forward gears,12 reverse gears, gear are reasonable,high working efficiency;

4.Adopt independent power output device,steady transmission,large bearing capacity;

5.Using independent oil hydraulic steering system operation,flexible operation,reliable energy saving;

6.Using disc brakes,large braking torque,good braking effecting;

7.Using forced type lifter, reliable use, convenient maintenance;

8.Final drive adopts planetary reduction structure,compact structure, large reduction ratio;

9.New streamlined appearance, greaceful ,HY,fashion;

Main technical parameters:

model

LT1004

type

4X4

Overall dimension(mm)

Length

4080

Width

1750

High

2650

wheelbase(mm)

2010

Front wheel tread(mm)

1285

Rear wheel tread(mm)

1340

Min.turning radius(m)

One side brake

4.2±0.3

One side not brake

4.9±0.3

Min.using mass

3030

Gear box

12F+12R

Speed(km/h)

going

0.44-33.34

retread

0.59-10.31

Engine

model

4C6-10035

Rated power(kw)

73.5

Rated speed(r/min)

2400

Tyre type

Front tyre

9.5-24

Rear tyre

14.9-30

Steering system type

All hydraulic front wheel steering

Max.lift-off weight(KN)

17.7

PTO type

Rear-mounted semi-detached

PTO speed(r/min)

760/1000(540/1000 or 540/760 or 760/850 is also available)

PTO power(kw)

62.5

Roots in control mode

Height adjustment,floating control

Max.traction(KN)

23.2

Counterweight quality(kg)

front

270
