Cross Linked Polyolefin Shrink Tubing 4mm 4x Black Shrink Tubing
Cross Linked Polyolefin Shrink Tubing 4mm 4x Black Shrink Tubing
Cross Linked Polyolefin Shrink Tubing 4mm 4x Black Shrink Tubing
Cross Linked Polyolefin Shrink Tubing 4mm 4x Black Shrink Tubing
Specifications
Brand Name :
Long
Model Number :
SBRS-4(X)GBK
Certification :
ISO
Place of Origin :
China
MOQ :
10m
Payment Terms :
T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :
400000meters per day
Delivery Time :
1-9days
Packaging Details :
Roll/Carton
Material :
PE
Colour :
Black
Shrink ratio :
4:1
Feature :
Seals and protects against water, moisture and chemicals
Adhesive bonds readily to :
PVC, XLPE and PP-EPDM
Shrinks rapidly for :
quick installation
Continuous operating temperature :
-45°C-125°C
Initial shrinkage temperature :
70°C
Description

5/32 4mm Black 4X Adhesive-Lined Cross-Linked Polyolefin Tubing

Adhesive lined heat shrink specifically designed to insulate, seal and protect inline splices in automotive wire harnesses and electronic assemblies.

Features

4:1 shrink ratio allows for fewer sizes to cover numerous splice configurations and diameters.

Seals and protects against water, moisture and chemicals

Adhesive bonds readily to PVC, XLPE and PP-EPDM

cable jackets

Shrinks rapidly for quick installation

Continuous operating temperature:-45°C-125°C

Initial shrinkage temperature:70°C

Fully shrink Temperature:^110°C

Dimensions

Size Expanded After Recovery
Internal Internal Total Wall Adhesive Standard Package
Inch mm Diameter Diameter Thickness Thickness
Min(mm) Max(mm) Nom(mm) Nom(mm)
5/32 4 4.0 0.95 1.40±0.30 0.60±0.20 1.22OR25M/Roll
1/4 6 6.0 1.27 1.70±0.30 0.80±0.20 1.22OR25M/Roll
5/16 8 8.0 1.65 2.00±0.30 0.95±0.20 1.22OR25M/R0II
2/5 10 10.0 2.00 2.20±0.40 1.10±0.20 1.22 OR25M/Roll
1/2 12 12.0 2.41 2.45±0.40 1.20±0.20 1.22OR25M/Roll
3/4 18 18.0 4.45 2.60±0.40 1.34±0.30 1.22OR25M/Roll

Technical Data

I Property Test Method Standard Typical Performance I
Tensile Strength(MPa) ASTM D2671 ^10.4 11.5
Elongation(%) ASTM D2671 N300 450
Tensile Strength after aging (MPa) UL224 158°CX168hr N7.3 8.5
Elongation after aging(%) UL224 158°CX168hr N200 350
Dieletric strength(kV/mm) IEC 60243 M15 17.5
Volume resistivity(Q.cm) IEC 60093 >1X1014 2.5X1014

Adhesive

Property Test Method Standard I
Water Absorption ASTM D570 <0.2%
Sofening Point(°C) ASTM E28 90±5
Strength of pearing(PE) ASTM D 1000 120N/25mm
Strength of pearing(AL) ASTM D 1000 80N/25mm
