Pure Nickel 201/N 02201/2.4061/N7 Commerciall For Heat Exchangers In Extreme Conditions
Pure Nickel 201/N 02201/2.4061/N7 Commerciall For Heat Exchangers In Extreme Conditions
Pure Nickel 201/N 02201/2.4061/N7 Commerciall For Heat Exchangers In Extreme Conditions
Pure Nickel 201/N 02201/2.4061/N7 Commerciall For Heat Exchangers In Extreme Conditions
Pure Nickel 201/N 02201/2.4061/N7 Commerciall For Heat Exchangers In Extreme Conditions
Pure Nickel 201/N 02201/2.4061/N7 Commerciall For Heat Exchangers In Extreme Conditions
Specifications
Brand Name :
Senphus
Model Number :
Nickel201/N 02201/2.4061/N7
Certification :
ISO9001
Place of Origin :
China
MOQ :
5kg
Payment Terms :
T/T, D/P
Supply Ability :
30 Tons per day
Delivery Time :
3 days
Packaging Details :
Packed with waterproof paper or weave bag, into pallets or wooden case. Special packaging requirements can also be accommodated.
Place of Orig. :
Jiangsu, China
Application :
Hydrogen industry
Density :
8.89
Thermal Conductivity :
70.2
Thermal Linear Expansion Coeff. (20-95 °C) :
13.3
Electrical Resistivity at 20°C :
9
Color :
Silvery white
Tensile strength（N/mm²） :
400-550
Elongation（% at L0=100 mm） :
20-30
Description

Pure Nickel 201/N 02201/2.4061/N7 Commerciall for Heat Exchangers in Extreme Conditions

Pure Nickel 201 (N02201/2.4061/N7) is a commercially pure nickel alloy with a minimum nickel content of 99.6%. It is widely recognized for its excellent corrosion resistance, high thermal and electrical conductivity, and outstanding mechanical properties, making it ideal for various industrial applications.Nickel 201 is a versatile, high-performance alloy suitable for environments requiring high corrosion resistance, excellent mechanical properties, and reliable performance.

Trade Code

GB ASTM DIN

NS 5201
N7

H 02201

Nickel 201

N 02201

 W-Nr.2.4061

Nominal Chemical Composition (%)

Alloy Ni Mn Fe Si Cu C Ti
Ni200 ≥ 99.2 ≤ 0.30 ≤ 0.20 ≤ 0.10 ≤ 0.20 ≤ 0.10 ≤ 0.10
Ni201 ≥ 99.2 ≤ 0.30 ≤ 0.20 ≤ 0.10 ≤ 0.20 ≤ 0.05 ≤ 0.10
Ni205 ≥ 99.6 ≤ 0.20 ≤ 0.20 ≤ 0.10 ≤ 0.10 ≤ 0.05 ≤ 0.05

Size Range

Type Dia. (mm) Width (mm) Thickness (mm)
Wire 0.04 - 12.0 - -
Ribbon - 2.0 ≥ 0.08

Physical Properties (at room temperature)

Alloy Density (g/cm3) Thermal Conductivity (W/m K) Thermal Linear Expansion Coeff. (20-95 ℃) (10-6/K) Electrical Resistivity at 20 ℃ (μΩ-cm)
Ni200/201 8.89 70.20 13.3 9
Ni205 8.89 75.00 13.3 8.9

Mechanical Properties (for cold drawn annealed wire)

Alloy Tensile strength (N/mm2) Elongation (% at L0=100mm)
Min Max Min Max
Ni200/201 400 550 20 30
Ni205 400 530 20 30

Key features of Nickel201/N 02201/2.4061/N7 alloy:

  • High Purity (99.6% Nickel Minimum)

Ensures excellent performance in corrosive and high-purity environments.

  • Exceptional Corrosion Resistance

Resistant to alkalis, particularly caustic soda, and effective against organic and inorganic acids.

Suitable for marine environments due to its resistance to seawater corrosion.

  • Mechanical Properties

Moderate tensile strength (55-75 ksi) with high ductility and toughness.

Performs well in both low and high temperatures, retaining mechanical integrity.

  • High Thermal and Electrical Conductivity

Offers excellent conductivity, making it suitable for electrical and electronic applications.

  • Non-Magnetic

Ideal for applications where magnetic interference must be avoided.

  • Good Fabricability

Easily formed, machined, and welded into various shapes, including wires, sheets, and tubes.

  • Temperature Stability

Maintains excellent performance in high-temperature applications up to 600°C (1112°F).

Applications:

  • Chemical Processing: Heat exchangers, reactors, and storage tanks.
  • Marine and Aerospace: Corrosion-resistant components.
  • Electronics: Electrical contacts, connectors, and resistance wires.
  • Other Industries: Food processing, medical equipment, and battery components.
