Pharmaceutical Industry Super Duplex Shell Tube Condenser For Fluoro Chemicals
Pharmaceutical Industry Super Duplex Shell Tube Condenser For Fluoro Chemicals
Specifications
Style :
Steel Type
Certification :
ASME U/ISO9001/ ISO45001/ ISO14001/PED/CE/CRTU/DOSH
MOQ :
1 Set
Size :
Customzied
Usage :
Oils and Fats Industry,Pharmaceutical industry，Oils and Fats Industry， etc
Material :
Carbon Steel/SS/Duplex SS/Titanium/Nickel-Based Alloy/Copper Alloy
Price :
Negotiation
Supply Ability :
6000sets/Year
Brand Name :
Yiteng
Delivery Time :
45-60 working days
Model Number :
WFE/SPD/BEM/BES/AES/BEU/TFE
Place of Origin :
Jiangsu China
Payment Terms :
T/T,L/C
Application :
Heater, Cooler, Condenser
Packaging Details :
Steel saddle+LDPE foil+Tarpaulin/Wooden box
MOQ :
1set
Description
Super Duplex Shell And Tube Condenser For Fluoro Chemicals
Product Description
A shell and tube condenser is a special type of shell-and-tube heat exchanger engineered for vapor condensation processes.In typical working conditions, hot vapor enters the shell side and releases latent heat when contacting the cold tube wall, then condenses into liquid and drains from the bottom outlet. Cooling medium such as cooling water, glycol or chilled liquid flows through the tube side to continuously take away heat.
Multiple structural designs are available including fixed tube sheet, U-tube, floating head and vertical shell tube condenser. A full range of construction materials can be customized: carbon steel, SS304, SS316L, duplex 2205, copper alloy and titanium to adapt to clean, scaling, high-chloride and corrosive media.
Our shell and tube condensers are designed and manufactured in accordance with GB/T 151, ASME VIII Div.1, TEMA, EN 13445, API 660, as well as TR CU 032/2013 and corresponding GOST standards for the Russian EAEU market.

Parameter

Super Duplex 2507

Technical Benefit

PREN Value

>40

Excellent pitting and crevice corrosion resistance

Yield Strength

≈550 MPa

About 2× 316L

Tensile Strength

≈800 MPa

Suitable for high-pressure service

Chloride Resistance

Excellent

Ideal for seawater applications

Temperature Range

-50°C to 300°C

Wide operating range

Design Life

>20 years

Lower lifecycle cost

Product parameter

Why Partner With Us?

· 1:1 Drawing Optimization: Our engineering team reviews and optimizes your blueprints to reduce production costs.

· Reliable Lead Time: Streamlined manufacturing process ensures your project timeline is protected.

· Global Shipping Experience: Full support for sea freight, customs clearance, and documentation.

Let's discuss your next project!
