C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm
C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm
C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm
C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm
C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm
C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm
C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm
C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm
Specifications
Brand Name :
Reliance
Model Number :
L TYPE
Certification :
CE,ISO...
Place of Origin :
China
MOQ :
N/A
Price :
N/A
Payment Terms :
T/T, L/C
Supply Ability :
Daily capacity up to 5,000 Meters
Delivery Time :
As per clients' request if any urgent.
Packaging Details :
Steel frame case sealed by plywoods with each tube end capped
Compamy Type M :
manufacturer, Importer & Exporter
Fin Tube Type :
L Type Fin Tube,Tension Wound L Type Fin Tube
Origin :
China
Nearest Port :
Shanghai Port, China
Description

L Type fin tube, core tube material C70600, OD25.4X1.245 with copper fins material C12200

ASTM B111/ B111M : Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock

Quick Detail:

Special order with fastest delivery within 2 weeks for power plant in Saui Arabia in Sep of 2015.

(1) All detailed order specifications as below.

Tube material: ASME B111 C70600
Tube Size :OD 25.4mm X1.245mmWT
Fin material: C12200
Fin O.D. : 57.15mm
Fin thickness: 0.4mm
Fin height: 15.8mm
Fin per inch: 11

Plain ends: 25.4mm+50.8mm

(2) Manufacturing process:

The copper strip is folded into an L SHAPE and wound onto the base tube surface under tension.

The feet of the fins are joined together and cover the finned surface.

(3) Delivery Condition

Tube ends are square cut, free burrs, internally dried and air blown clean.

(4) Packing

The desiccants are put into each package for continental transportation as well.

(5) Applications

An urgent replancement job during the shutdown of power plant.

(6) Other Specifications

All dimensions are in Inches and specification upon your requests.

Tube OD

Fin Height

Fin Thickness

Fins per Pitch

5/8

3/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

3/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/2

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

Pease email us for more information.

C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm

C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm

C12200 C70600 Core L/LL/KL Type Fin Tube OD25.4X1.245mm
