Portable LED Finger Pulse Oximeter New Design Export Only Blood Oxygen Monitor

Fingertip Pulse Oximeter Operation:

1) SpO2 value display
2) Pulse rate value display, bar graph display
3) Pulse waveform display
4) PI value display
5) The display mode can be changed
6) Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage
7) Pulse sound indication and over limit indication

Fingertip Pulse Oximeter Parameters

Fingertip Pulse Oximeter Features

• Display Mode:0.96" LED display

• Screen Resolution:128*64

• SpO2 Measuring Range:0%~100%, (the resolution is 1%), accuracy:70%~100%:±2% ,Below 70% unspecified.

• PR Measuring Range:30 bpm~250 bpm, (the resolution is 1 bpm), accuracy:±2 bpm or ±2% (select larger)

• PI Measuring Range: 0 %~ 20%, accuracy:When the PI measure range is 1%~20%,the permission of absolute error is ±1%. When the PI measure range is 0%~0.9%,the permission of absolute error is ±0.2%

• Measurement Performance in Weak Filling Condition:SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).

• Resistance to surrounding light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%

• Power Consumption:less than 80 mA

• Voltage: DC 2.6 V - 3.6 V

• Power Supply:1.5 V (AAA size) alkaline batteries × 2

• Safety Type:Interior Battery,BF Type
