| Input power | AC100V~240V 50/60Hz |
| Light source specifications | 7pcs 40W four-in-one LED Osram light sources |
| Approved life | 50000 hours |
| Color | Red, green, blue and white colors |
| Focus | 4 .5° - 45 ° DMX linear focus, with auto focus function |
| Color temperature regulation | Built-in CTO DMX linear dimming |
| Electronic strobe | 0.3 ~ 25 times / sec, can choose synchronous, asynchronous random strobe |
| Dimming | Electronic dimming 0 ~ 100% linear adjustment |
| Rotation angle | XY axis adopts high-speed silent 57 three-phase motor drive, with high-precision imported Hall positioning device |
| Control mode | 23 (simplified) 35/51 (standard) 4 channel control modes, standard DMX512 protocol, RDM protocol |
| Control interface | DMX512 interface (3-core / optional 5-core), power cord hand socket |
| Feature | Screen automatic rotation function |
| Protection level | IP20, optional rain cover protection level up to IP44 |
| Packing | Waterproof and shockproof Flight Case or Carton |
| Net weight/Gross weight | 10kg/12kg |
| Product size | 34*23*41CM |
| Effect mode | swirl, kaleidoscope |
