Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Specifications
Brand Name :
Geomax
Model Number :
100-712
Certification :
CE
Place of Origin :
ANHUI CHINA
MOQ :
1000 ㎡
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
2000㎡ per day
Delivery Time :
10-20 days
Packaging Details :
Folded strips are wrapped by film and layed on pallets or as requested
Material :
HDPE
Type :
150-445
Color :
Black
Welding space :
445mm
Thickness :
1.5mm
Height :
150
Surface :
Textured
Standard :
ASTM
Description

PRODUCT DESCRIPTION

Erosion Control Black HDPE Geocells Ground Grid Paver Soil Reinforcement Slope Protection

Product Introduction

Geocell is a new type of high-strength geosynthetics, which is popular in domestic and abroad. It is a kind of three-dimensional network structure shaped by high-strength HDPE sheets through ultrasonic welding of high strength. Currently, it is being widely used in construction, such as highway, railway, bridge, dyke, etc.

Specifications

Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150
Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18

Application

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

SOIL REINFORCEMETN

Geomax®(Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

SLOPE PROTECTION

Geomax®(Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

CHANNEL PROTECTION

Geomax®(Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

RETAINING WALLS

Geomax®(Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.

HCNS Manufacture

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

Exhibition Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

Our Certificates and HDPE Geocell Testing reports

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
