Specifications
Brand Name :
Geomax
Model Number :
100-712
Certification :
CE
Place of Origin :
ANHUI CHINA
MOQ :
1000 ㎡
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
2000㎡ per day
Delivery Time :
10-20 days
Packaging Details :
Folded strips are wrapped by film and layed on pallets or as requested
Material :
HDPE
Type :
100-712
Color :
Black
Welding space :
712mm
Thickness :
1.5mm
Height :
100
Surface :
Perforated
Standard :
ASTM
Description

PRODUCT DESCRIPTION

Plastic Driveway Gravel Grid Geocells For Soil Stabilization Hdpe Geocell Retaining Walls

Product Introduction

Geocell is made of reinforced HDPE sheet material, by high strength welding (generally ultrasonic needle welding) and formed a
three-dimensional mesh cell structure. For engineering needs, some can be punched on the diaphragm. It is used to stabilize the
road and railway subgrade, bear the load of embankments and shallow river governance, and prevent landslide and load of mixed
retaining wall.
In the soft foundation, the use of geocell can greatly reduce the construction labor intensity and the thickness of the subgrade.With fast construction speed and good performance,it greatly reduce the cost of the project.

Specifications

Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150
Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18

Application

High Strength Driveway Gravel Geocell Ground Grid Paver For Slope Protection

SOIL REINFORCEMETN

Geomax®(Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.

High Strength Driveway Gravel Geocell Ground Grid Paver For Slope Protection

SLOPE PROTECTION

Geomax®(Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.

High Strength Driveway Gravel Geocell Ground Grid Paver For Slope Protection

CHANNEL PROTECTION

Geomax®(Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.

High Strength Driveway Gravel Geocell Ground Grid Paver For Slope Protection

RETAINING WALLS

Geomax®(Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.
