1.6mm Thickness High Frequency Board ENIG Surface Finish For Audio Amplifier
1.6mm Thickness High Frequency Board ENIG Surface Finish For Audio Amplifier
1.6mm Thickness High Frequency Board ENIG Surface Finish For Audio Amplifier
1.6mm Thickness High Frequency Board ENIG Surface Finish For Audio Amplifier
Specifications
Brand Name :
ACCPCB
Model Number :
P1116127
Certification :
ISO, UL, SGS,TS16949
Place of Origin :
China
MOQ :
10PCS
Price :
Negotiable
Payment Terms :
L/C / T/T / Western Union / Paypal
Supply Ability :
30,000SQ.M/Per Month
Delivery Time :
10-12days
Packaging Details :
Vacuum packing with desiccant
Material :
FR4
Thickness :
1.60mm
Surface Finish :
ENIG
Layer :
6L
Pcb standard :
IPC-A-610 D
Usage :
OEM Electronics
Description

1.6mm thickness high frequency board with size :160mm x 100mm for audio amplifier application

Production description :

this board is 6layer with 1oz copper thickness. it is used for audio amplifier. we can accept any quantity board such as PCB prototype,samll volum, middle and large volume . no MOQ request for new order. all of these boards are met UL,TS16949, ISO9001 Etc.

Key Specifications/Special Features :

Layer : 6 Layers
Base Material : FR4
Copper Thickness : 1oz in all layer
Board Thickness : 1.60mm
Min. Hole Size : 8 mil
Min. Line Width : 6 mil
Min. Line Spacing : 6 /mil
Surface Finishing : immersion gold
Solder Mask Color : Blue
Certificate : UL, CQC, TS16949, ISO14000, ROHS
Silkscreen color : White
Outline : Routing

Quality assurance :

  • Every production process has a special person to test to ensure quality, AOI, E-testing, Flying Probe Test.
  • Have professional engineers to check the quality
  • All products have passed CE, FCC, ROHS and other certifications

Advantages:
• Strict product liability, taking IPC-A-160 standard
• Engineering pretreatment before production
• Production process control (5Ms)
• 100% E-test, 100% visual inspection, including IQC, IPQC, FQC, OQC
• 100% AOI inspection, including X-ray, 3D microscope and ICT
• High-voltage test, impedance control test
• Micro section, soldering capacity, thermal stress test, shocking test
• In-house PCB production
• No minimum order quantity and free sample
• Focus on low to medium volume production
• Quick and on-time delivery

Lead Time :

Lead Time 2 /L 4 /L 6/ L 8/ L
Sample Order 3-5days 6-8days 10-12days 12-14days
Mass Production 7-9days 8-10days 12-15days 15-18days
FQA :

1. How do ACCPCB ensure quality?

Our high quality standard is achieved with the following.

1.1 The process is strictly controlled under ISO 9001:2008 standards.
1.2 Extensive use of software in managing the production process
1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
1.4.Dedicated quality assurance team with failure case analysis process

2. What kinds of boards can ACCPCB process?

Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.


3. What data are needed for PCB production?

PCB Gerber files with RS-274-X format.


4. What’s the typical process flow for multi-layer PCB?

Material cutting → Inner dry film → inner etching → Inner AOI → Multi-bond→ Layer stack up Pressing → Drilling → PTH → Panel Plating → Outer Dry Film → Pattern Plating → Outer etching → Outer AOI → Solder Mask → Component Mark → Surface finish → Routing → E/T → Visual Inspection.


5. How many types of surface finish ACCPCB can do?

O-the leader has the full series of surface finish, such as: ENIG, OSP, LF-HASL, gold plating (soft/hard), immersion silver, Tin, silver plating, immersion tin plating, carbon ink and etc. .. OSP, ENIG, OSP + ENIG commonly used on the HDI, we usually recommend that you use a client or OSP OSP + ENIG if BGA PAD size less than 0.3 mm.

6. How to you make the impedance calculation?

The impedance control system is done using some test coupons, the SI6000 soft and the CITS 500s equipment
