10 Layer 1.6mm High Density PCB Impedance Gold For Security Equipment
10 Layer 1.6mm High Density PCB Impedance Gold For Security Equipment
10 Layer 1.6mm High Density PCB Impedance Gold For Security Equipment
10 Layer 1.6mm High Density PCB Impedance Gold For Security Equipment
Specifications
Brand Name :
ACCPCB
Model Number :
P121012
Certification :
ISO, UL, SGS,TS16949
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable
Payment Terms :
L/C / T/T / Western Union / Paypal
Supply Ability :
30000SQ.M/PER MONTH
Delivery Time :
12-15Days
Packaging Details :
Vacuum packing with desiccant
Number of layer :
12L
Material :
ITEQ FR4 tg150
Finish copper thickness :
1oz in inner layer and 2oz out layer
Surface finish :
immersion gold
Min Holes :
0.25mm
Application :
Security equipment
Description

10 Layer 1.6mm High Density PCB Impedance Gold for Security Equipment

Production description :

this board is 10layer with 1 / 2oz copper thickness. it is used for security equipment.all of these boards are met UL,TS16949, ISO9001 etc. we can accept any quantity board such as PCB prototype,samll volum, middle and large volume . no MOQ request for new order.

Production Feature :

Layer :10 Layers
Base Material : ITEQFR4
Copper Thickness :1 oz outlayer / 2 oz inner layer
Board Thickness :1.60 mm
Min. Hole Size : 0.25 mm
Min. Line Width :0.12 / 0.12 mm
Min. Line Spacing : 0.12 / 0.12 mm
Surface Finishing : immersion gold
Solder Mask Color :Green
Certificate : UL, CQC, TS16949, ISO14000, ROHS
PTH tolerance : +/-3mil
NPTH tolerance : +/-2mil
Silkscreen color : white


Company description :

ACCPCB is a high-tech enterprise specializing in the production and sales of double-sided and multi-layer rigid circuit boards in Boluo County, Huizhou City. It has an independent property factory of about 20,000 square meters, more than 500 employees, and an annual design production capacity of 500,000 square meters. The company has passed ISO9001 and ISO14000 quality and environmental system certification, and has obtained UL certification of the United States. The process capability is comprehensive and the technical strength is strong. The products fully comply with the EU RoHS directive green environmental protection requirements. The company aims to become a first-class professional circuit board manufacturer, providing the highest quality products and services based on quality assurance, we listen to the voice of our customers, establish a good relationship with all customers, and make progress together and grow together.

Advantages:

• Strict product liability, taking IPC-A-160 standard
• Engineering pretreatment before production
• Production process control (5Ms)
• 100% E-test, 100% visual inspection, including IQC, IPQC, FQC, OQC
• 100% AOI inspection, including X-ray, 3D microscope and ICT
• High-voltage test, impedance control test
• Micro section, soldering capacity, thermal stress test, shocking test
• In-house PCB production
• No minimum order quantity and free sample
• Focus on low to medium volume production
• Quick and on-time delivery

FAQ


1. What kinds of boards can ACCPCB process?
Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.
2. What data are needed for PCB production?
PCB Gerber files with RS-274-X format.
3. What’s the typical process flow for multi-layer PCB?
Material cutting → Inner dry film → inner etching → Inner AOI → Multi-bond→ Layer stack up Pressing → Drilling → PTH → Panel Plating → Outer Dry Film → Pattern Plating → Outer etching → Outer AOI → Solder Mask → Component Mark → Surface finish → Routing → E/T → Visual Inspection.
